ADT PCIe 4.0 x1 to x4 Riser Cable Gen4 PCI-E x1 to x4 Extension Cable for WiFi NIC, LAN Card, Capture Card, USB Adapter, SSD Card, Custom Length 3~100cm

Subtitle

ADT M12 Series PCIe4.0 x1 to x4 extender | Factory Direct | 100% Power Tested | Custom Cable Length Available

Product DescriptionProduct Overview

ADT factory direct sale. Every cable passes 100% full power-on inspection before shipment to ensure quality.

Brand: ADTModel: M12 Series
Product Name: PCI-E 4.0 x1 to x4 Riser Extension Cable
Cable Length: 3cm ~ 100cm, custom length available
Bandwidth & Speed: PCIe 4.0 x1 Gen4, up to 16Gbps

Compatible Cards:Wireless network card, wired LAN card, video capture card, USB expansion card, PCIe SSD card.Compatible with PCIe x4 cards installed into motherboard PCIe x1 slot.

Product Advantages

1. High-Speed Shielded CableADT self-developed 4th-generation shielded high-speed flat cable with premium connectors. Delivers stable transmission at PCIe4.0 x1 up to 8Gbps.
2. Flexible Custom LengthCustom lengths from 3cm to 100cm. Low-impedance flat cable maintains full PCIe4.0 speed stably for lengths up to 60cm.
3. Via-Free Differential Signal DesignEliminates parasitic capacitance, parasitic inductance and related signal attenuation & interference. Prevents CAF micro-short circuit issues for extended service life.
4. Premium High-Frequency PCBHigh-frequency low-loss PCB with high TG substrate. Copper thickness upgraded to 1oz. Gold-plated edge fingers with sufficient gold plating for excellent conductivity. Reduces oxidation and rising resistance that cause system crashes or audio static.
5. Heavy-Duty Reinforced Construction3mm thick PCB gaskets protect soldering joints, secured with screws and hex lock nuts. Tensile resistant, anti-interference, prevents wire breakage and pin loss.
6. Low-profile & Enlarged PCB DesignLow-profile PCB avoids conflict with graphics cards. Enlarged & extended PCB design simplifies installation and lowers risk of damage.

FAQ

Q: What is the cable quality? Does it have shielding?A: It features metal-layer shielding with advanced EMI shielding conductive polymer material for flat ribbon cable. This technology fully covers every cable with conductive polymer EMI shielding. It blocks incoming and outgoing electromagnetic radiation, minimizes interference and performance degradation, while keeping the cable lightweight.

Q: How thick is the cable? Is it flexible and bendable?A: The flat cable is only 1.3mm thick. It is soft and can be bent freely without affecting normal usage.

Important Purchase Notes

1. Correct Installation Direction: Check the orientation carefully before plugging in. Reversed or misaligned insertion may burn your hardware. Hold the device connector firmly when inserting the cable to avoid breaking connector pins by excessive force. Do NOT bend or pull the cable within 2cm of the soldering joints at both ends.
2. Signal Loss Disclaimer: Motherboards and hardware have different signal driving capabilities. Our in-house test results may differ from your setup. Signal loss always occurs when using extension cables. Do not purchase if you require absolutely perfect signal performance.
3. Hardware Age Limitation: Graphics cards and motherboards degrade and oxidize over time. Older hardware will become even less stable with riser cables. Not compatible with hardware older than 4 years. Do not buy for aged devices.
4. Intended Use: Designed for purchase and use by professional engineers for product testing only. Not recommended for other applications.

Package Includes

1 × ADT PCIe4.0 x1 to x4 Riser Cable (selected custom length)
