Overview
The Adtran Total Access® 5000 SM200 100GSwitch Module enhances the already robust,carrier-class switching capability of the TotalAccess 5000 Fiber Access, Aggregation, andTransport platform. Offering 2x40 and 2x100Gigabit Ethernet (40GE/100GE) network andring interfaces, the SM200 switch modulesimplifies upgrading FTTP networks to 10G Next-Gen PON. Additionally, it enables operatorsto extend the life of their ODN while providingan architecture that supports cost-effectivebusiness and backhaul services delivery atmultigigabit speeds.With the ability to be deployed in both CentralOffice and Remote Terminal locations, theSM200 100G Switch Module provides flexiblenetwork deployment options, easily scaling tosupport symmetric multi-Gigabit services forresidential, business and mobile applications,triple-play services, Metro Ethernet, and serviceaggregation using 40G/100G Network Interfacesand Ethernet Ring Protection Switching(ERPS) support for network transport.The Total Access 5000 SM200 Switch Moduleprovides four flexible interfaces on the faceplatewhich can be used in a variety of waysdepending on application needs. The SM200Switch Module has two Quad Small Form-FactorPluggable+ (QSFP+) optical interfacessupporting 10G/40G rates, and two QSFP28interfaces that support 40G/100G rates. Inaddition, ports of the same speed may be configuredto support IEEE 802.1ax link aggregationto increase the bandwidth between nodes ortoward the core network.The Total Access 5000 SM200 Switch Modulesupports ITU G.8032 ERPS which providesnetwork operators with the ability to createresilient 10G, 40G or 100G Ethernet rings withmultiple Total Access 5000 Nodes. ERPS givesoperators the ability to increase their networkfootprint and size while maintaining a singleaccess point to their IP/Ethernet core.To support Next-Gen 10G PON (XGS-PON andCombo PON) service delivery, the SM200 SwitchModule supports high-capacity Nx100G switchfabric and provides non-blocking connectivityto every access module slot. The increasedcapacity of the switch fabric for the TotalAccess 5000 SM200 Switch Module allowsoperators to scale both network and subscriberbandwidth for years to come—without a forkliftreplacement. The SM200 Switch Module issupported in all currently deployed Total Access5000 systems and is backward compatible withall existing Total Access 5000 access and linemodules.Like all Total Access 5000 Switch Modules, theSM200 provides traffic management featuresto support differentiated quality of service aswell as enhanced security features to protectuser data from external attacks. This switchmodule can be deployed either simplex orredundant to support even the most criticaltraffic.
Product Specifications
Interfaces
● Two 40GE QSFP+ Uplinks- 10GE or 40GE Configurable● Two 100GE QSFP28 Uplinks- 40GE or 100GE Configurable
Features
● Redundant or Non-Redundant Operation● 802.3ah Ethernet OAM ConnectivityFault Management● 802.1p Class of Service (CoS)● 802.1Q VLAN Tagging● 802.1ad Q-in-Q VLAN Topologies● 802.3ad Link Aggregation (LACP)● ITU G.8032 Ethernet Ring Protection (ERPS)● 1:1, N:1, and Hybrid N+1:1 VLAN Topologies● Multicast Packet Replication for IPTV Applications● Network and Subscriber Proxy ARP● IGMP Version 2 Proxy and Snooping● IGMP Version 3 LITE● VoIP Protocols, SIP/MGCP, or Traditional VoiceGateway Functionality (GR-303)● IGMP v2, v3 and MLDv2 Support
Management
● Mosaic Software Suite● Advanced Operational Environment (AOE)● Remote Management Through SNMP, CLI, andWeb-Service APIs (HTTPS)● Ethernet Interface on SCM for Web and Telnet/SSHAccess (In-Band or Out-of-Band)● Craft and Ethernet Interfaces on SCM
Physical
● Requires SMIO4 (Switch Module Input/Output)● Dimensions: 9.5 in. x 0.75 in. x 9.0 in(241 mm x 19 mm x 228 mm) (H x W x D)
Environmental
● Operating Temperature: -40°F to 149°F(-40°C to +65°C)● Storage Temperature: -40°F to 185°F(-40°C to +85°C)● Relative Humidity: Up to 95%, Non-condensing
Regulatory Standards
● NEBS Level 3- GR-1089-CORE- GR-63-CORE● CE Marking (EMC and Low Voltage Directive)- ETSI EN 300 386- IEC 62368-1● FCC Part 15 Class A● UL/CUL 62368-1● AS/NZS 62368.1
Benefits
- Increases Uplink Capacity to Nx100G
- Supports 40GE/100GE ERPS Rings
- Supports High Density Triple-Play Service Deployments
- Increases Access Slot Capacity to Support High-Capacity, Unblocked, Next-Gen 10G PON (XGS-PON) Services
- Enhanced Security to Protect Against “Spoofing” Attacks and Service Theft
- CoS Support for Multi-Service Deployments, Protecting Video Quality
- FTTP Convergence of Both Business Ethernet and Residential Gigabit Services on the Same Shelf
- Offers Two QSFP+ (10GE/40GE) and Two QSFP28 (40GE/100GE) Interfaces Supporting Simplex or Redundant Architectures
- Resilient Ring Protection via ERPS (G.8032) Support
