Overview
Combo PON makes upgrading to symmetrical10G PON services simple by seamlessly supportingthe installed base of GPON subscriberswhile blanketing the entire Fiber-to-the-Home (FTTH) network with the higher speedand capacity of symmetric 10 Gbps XGS-PON.The Adtran Total Access® 5000 10G ComboPON OLT Access Module supports cost-effectiveservices delivery at multi-gigabit speeds.The biggest challenge facing 10G FTTH serviceproviders is deploying a single solution thatmeets the demands of premium business andbackhaul services while, at the same time,delivering an attractive price point neededfor mass-market residential applications.The 10G Combo PON OLT module supports aflexible optics approach that allows for eachof the eight faceplate ports to independentlyutilize multiple types of transceivers. This allowsservice providers the flexibility to determinethe right technology (GPON or XGS-PON) forresidential FTTH while also providing capacityfor high-bandwidth business and mobile backhaulservices. Any mix of technologies - GPON,XGS-PON or both - are supported on a per-portbasis simplifying migration to 10G FTTH, deliveringmaximum flexibility without compromisingfuture capabilities.The TA5000 10G Combo PON OLT supportsdelivery of both cost-effective GPON and competitivemulti-gigabit XGS-PON services overthe same Optical Distribution Network (ODN),with the added benefit of GPON inheritance.Service providers can swap installed GPON OLTmodules with Combo PON OLT modules, and allthe GPON configurations are preserved whileseamlessly enabling XGS-PON in the network.This flexibility of Combo PON allows for multiplerevenue generating services including residentialand business gigabit and multi-gigabitmobile backhaul, delivering higher revenue andbetter ROI at 50% lower CAPEX. In addition, byintegrating the coexistence element within theoptics, Combo PON delivers 25% greater gigabitservice coverage increasing your revenuepotential.SDN-Ready SolutionThe Total Access 5000 GPON OLT can bemanaged via the Adtran Mosaic CloudPlatform, our SDN control and orchestrationsolution, or the Advanced OperationalEnvironment (AOE), a traditional elementmanagement system.The Total Access 5000 GPON OLT worksin concert with the Adtran suite ofresidential CPE, which includes our latestWi-Fi 5/6 Service Delivery Gateways, Fiberto-the-Home Gateways, Mesh Wi-Fi, anda comprehensive portfolio of indoor andoutdoor GPON and XGS-PON ONTs.
Benefits

• Supports Symmetric Residential and Enterprise Services
• Extends Gigabit Service Coverage Area by 25% Increasing Revenue Potential
• Simplifies Move from GPON to XGS-PON with Limited Operational Impact and No Additional Equipment Space
• Extends FTTH Reach Up to 60 Km Simplifying Broadband Expansion to Rural and Remote Locations
• Supports an Extensive and Growing Family of ONTs
• Supports Both IPTV and RF Overlay Video Services
• Supports Dynamic Bandwidth Allocation Enabling Committed Rate Business Services
• Supports Service-Aware Provisioning and Troubleshooting
• Allows Both CO and RT Deployments

Product Specifications
Interfaces
● 8 (16)* 10G Combo PON Ports Capable of Supporting:

• GPON: B+, C+, C++, and D Class SFP Optics
• XGS-PON: N1 and N2 Class SFP+ Optics
• Combo PON: D1 and D2 Class SFP+ Optics
• *Supports Separate or Simultaneous GPON and XGS-PON Delivery Per Interface

● ITU-T Compliant GPON and XGS-PON ODN Range Configuration Support (Optical Budget Dependent)

• Standard: 20 km
• Extended: 37.5 km
• Maximum: 60 km

Capacities
● Capable of Up to 128 ONTs PerCombo PON Interface● Total Access 5000 23-inch Chassis

• 21 Access Modules; Up to 21,000 Subscribers Per Chassis (Utilizing 1:128 split)

● Total Access 5006+ Chassis

• Six Access Modules; Up to 6,000 Subscribers Per Chassis (Utilizing 1:128 split)

● Total Access 5004 Global Chassis

• Four Access Modules; Up to 4,000 Subscribers Per Chassis (Utilizing 1:128 split)

● Total Access 5004 Micro Cabinet

• 2 Access Modules; Up to 2,000 Subscribers Per Chassis (Utilizing 1:128 split)

Management
● Mosaic Software Suite● Advanced Operational Environment (AOE)● Remote Management Through SNMP, CLI, andWeb-Service APIs (HTTPS)● Ethernet Interface on SCM for Web and Telnet/SSHAccess (In-Band or Out-of-Band)● Craft and Ethernet Interfaces on SCM● OMCI to ONTs
Physical
● Dimensions: 9.5 in. x 0.75 in. x 9.0 in.(241 mm x 19 mm x 228 mm) (H x W x D)
Environmental
● Operating Temperature: -40° F to 158° F(-40° C to +65° C) (With High-Flow Fan)● Storage Temperature: -40° F to 185° F(-40° C to +85° C)● Relative Humidity: Up to 95%, at 122° F (50° C),Non-Condensing
Regulatory Standards
● Applicable UL/CUL Standards● Applicable EN/IEC/AS/NZS Standards● FCC Part 15 Class A● CE Mark (Meets Applicable Safety, EMC,Energy Efficiency Directives)● NEBS Level 3
