SPECIFICATIONS

ModelX8000A506-18

TypeATX

ModularFully

Dimension (W x L x H)150 x 170 x 86mm

Warranty10 years

Input Voltage100-240

Input Current15A ~ 7.5A

Input Frequency Range47Hz ~ 63Hz

PFCAPFC

PFC at half / full load:

>0.95 at AC 110v 60Hz(typical)

>0.90 at AC 230v 50Hz(typical)

Power Good Signal100 ~ 500mS

EfficiencyAt 20% / 50% / 100% load AC 115V internal,

the power efficiency should be at least 90% / 92% / 89%.

ProtectionOCP / OVP / UVP / SCP / OPP / OTP / SIP / NLO

Output Capacity1300W

Operation Temperature0 ~ 40°C

RegulatorycTUVus / TUV / CB [IEC62368 Compliant] / CE /

FCC / BSMI / 3C / KC / RCM

Fan135 x 135 x 25(mm) FDB Silent Fan

Certifications80 Plus Platinum

Connector1 x MB 24(20+4) Pin

2 x 8(4+4) Pin EPS 12V

12 x 8(6+2) Pin PCI-E

14 x SATA

5 x Molex

1 x FDD

UPC#0-761345-11705-0 SP1300

0-761345-11706-7 SP1300 AU

0-761345-11707-4 SP1300 EC

0-761345-11708-1 SP1300 GB

0-761345-11709-8 SP1300 JP

Net Weight2.12 Kgs

Gross Weight4.05 Kgs
