• Unique FeatureASRock USB 3.1 Gen2
  - ASRock USB 3.1 Gen2 Type-A Port (10 Gb/s)
  - ASRock USB 3.1 Gen2 Type-C Port (10 Gb/s)
  ASRock X Series OC Socket
  ASRock Super Alloy
  - XXL Aluminum Alloy Heatsink
  - Premium 60A Power Choke
  - Ultra Dual-N MOSFET (UDM)
  - Nichicon 12K Platinum Caps (100% Japan made high quality conductive polymer capacitors)
  - I/O Armor
  - Sapphire Black PCB
  - High Density Glass Fabric PCB
  ASRock Steel Slots
  ASRock 802.11ac WiFi
  ASRock Ultra M.2(PCIe Gen3 x4 & SATA3)
  ASRock Full Spike Protection
  ASRock Live Update & APP Shop
• CPU- Supports Intel®Core™ i7 and Xeon®22-Core Processors Family for the LGA 2011-3 Socket
  - Digi Power design
  - 12 Power Phase design
  - Supports Intel®Turbo Boost Max Technology 3.0*
  - Supports Untied Overclocking Technology

  *Intel®Core™ i7-59xx/58xx processors only support Intel®Turbo Boost Max Technology 2.0.
• Chipset- Intel®X99
• Memory- Quad Channel DDR4 Memory Technology
  - 8 x DDR4 DIMM Slots
  - Supports DDR4 non-ECC, un-buffered memory
  - Supports non-ECC RDIMM (Registered DIMM)
  - Supports DDR4 ECC, un-buffered memory/RDIMM with Intel®Xeon®processors E5 series in the LGA 2011-3 Socket
  - Max. capacity of system memory: 128GB (with Core™ i7 CPU Broadwell-E) or 64GB (with Core™ i7 CPU Haswell-E) or 256GB (With Xeon®CPU)*
  - Supports Intel®Extreme Memory Profile (XMP) 2.0
  - 15μ Gold Contact in DIMM Slots

  *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows®32-bit OS. For Windows®64-bit OS with 64-bit CPU, there is no such limitation.
  Please refer to Memory Support List on ASRock's website for more information.
• BIOS- 2 x 128Mb AMI UEFI Legal BIOS with multilingual GUI support (1 x Main BIOS and 1 x Backup BIOS)
  - Supports Secure Backup UEFI Technology
  - ACPI 5.0 Compliant wake up events
  - SMBIOS 2.7 Support
  - CPU, DRAM, PCH 1.05V, PCH 1.5V, VPPM Voltage Multi-adjustment
• Graphics- n/a
• Audio- 7.1 CH HD Audio with Content Protection (Realtek ALC1150 Audio Codec)
  - Premium Blu-ray Audio support
  - Supports Surge Protection (ASRock Full Spike Protection)
  - Supports Purity Sound™ 3
  - Nichicon Fine Gold Series Audio Caps
  - 115dB SNR DAC with differential amplifier
  - TI®NE5532 Premium Headset Amplifier (Supports up to 600 ohm headsets)
  - Pure Power-In
  - Direct Drive Technology
  - PCB isolate shielding
  - Supports DTS Connect
• LAN- Gigabit LAN 10/100/1000 Mb/s
  - 1 x Giga PHY Intel®I218V, 1 x GigaLAN Intel®I211AT
  - Supports Wake-On-LAN
  - Supports Lightning/ESD Protection (ASRock Full Spike Protection)
  - Supports Dual LAN with Teaming*
  - Supports Energy Efficient Ethernet 802.3az
  - Supports PXE

  *Not supported under Windows®10
• Wireless LAN- Supports IEEE 802.11a/b/g/n/ac
  - Supports Dual-Band (2.4/5 GHz)
  - Supports high speed wireless connections up to 433Mbps
  - Supports Bluetooth 4.0 / 3.0 + High speed class II
• Slots- 3 x PCI Express 3.0 x16 Slots (PCIE2 @ x16 mode; PCIE4 @ x16 mode; PCIE5 @ x0 mode) (PCIE2 @ x16 mode; PCIE4 @ x8 mode; PCIE5 @ x8 mode)*
  - 2 x PCI Express 2.0 x1 Slots
  - Supports AMD Quad CrossFireX™, 3-Way CrossFireX™ and CrossFireX™
  - Supports NVIDIA®Quad SLI™, 3-Way SLI™ and SLI™
  - 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT module
  - 15μ Gold Contact in VGA PCIe Slot (PCIE2 and PCIE4)

  *If you install CPU with 28 lanes, PCIE2/PCIE4/PCIE5 will run at x16/x0/x8 or x8/x8/x8.
  Supports NVMe SSD as boot disks.
• Storage- 10 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel®Rapid Storage Technology 13), NCQ, AHCI, Hot Plug*
  - 1 x SATA Express 10 Gb/s Connector (shared with SATA3_4 and SATA3_5)**
  - 1 x Ultra M.2 Socket (M2_2), support M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)***
  - 1 x Ultra M.2 Socket (M2_1), support M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)***

  *SSATA3_3 connector is shared with the M2_1; SSATA3_2 connector is shared with the M2_2.
  RAID is supported on SATA3_0 ~ SATA3_5 ports only.

  **Support to be announced.

  ***If you install CPU with 28 lanes, the M2_1 only supports SATA type M.2 module.
  Supports NVMe SSD as boot disks.
  Supports ASRock U.2 Kit.
• Connector- 1 x COM Port Header
  - 1 x TPM Header
  - 1 x Power LED and Speaker Header
  - 1 x CPU Fan Connector (4-pin) (Smart Fan Speed Control)*
  - 1 x CPU Optional/Water Pump Fan Connector (4-pin)**
  - 3 x Chassis Fan Connectors (4-pin)***
  - 1 x 24 pin ATX Power Connector
  - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
  - 1 x Front Panel Audio Connector
  - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
  - 1 x USB 3.1 Gen1 Headers (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection (ASRock Full Spike Protection))
  - 1 x Dr. Debug with LED
  - 1 x BIOS Selection Switch

  *The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.

  **The CPU Optional/Water Pump Fan supports the water cooler fan of maximum 1.5A (18W) fan power.

  ***CHA_FAN1 and CHA_FAN2 can auto detect if 3-pin or 4-pin fan is in use.
• Rear Panel I/O- 1 x PS/2 Mouse/Keyboard Port
  - 1 x Optical SPDIF Out Port
  - 3 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))
  - 1 x USB 3.1 Gen2 Type-A Port (10 Gb/s) (ASMedia ASM1142) (Supports ESD Protection (ASRock Full Spike Protection))
  - 1 x USB 3.1 Gen2 Type-C Port (10 Gb/s) (ASMedia ASM1142) (Supports ESD Protection (ASRock Full Spike Protection))
  - 3 x USB 3.1 Gen1 Ports (Intel®X99) (Supports ESD Protection (ASRock Full Spike Protection))
  - 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED)
  - 1 x Clear CMOS Switch
  - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
• Software and UEFISoftware
  - ASRock A-Tuning
  - ASRock Disk Health Report
  - ASRock USB Key
  - ASRock APP Charger
  - ASRock XFast LAN
  - ASRock XFast RAM
  - ASRock Restart to UEFI
  - ASRock Fast Boot (Fast Boot, Restart to UEFI)*
  UEFI
  - ASRock EZ Mode
  - ASRock Full HD UEFI
  - ASRock My Favorites in UEFI
  - ASRock UEFI Guide
  - ASRock Instant Flash
  - ASRock Internet Flash
  - ASRock Crashless BIOS
  - ASRock OMG (Online Management Guard)
  - ASRock UEFI System Browser
  - ASRock UEFI Tech Service
  - ASRock Easy RAID Installer
  - ASRock Easy Driver Installer

  *These utilities can be downloaded from ASRock Live Update & APP Shop.
• Support CD- Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• Accessories- Quick Installation Guide, Support CD, I/O Shield
  - 4 x SATA Data Cables
  - 1 x ASRock SLI_HB_Bridge_2S Card
  - 1 x ASRock SLI_Bridge_2S Card
  - 1 x ASRock 3-Way SLI-2S1S Bridge Card
  - 2 x ASRock WiFi 2.4/5 GHz Antennas
  - 2 x Screws for Ultra M.2 Socket
• Hardware Monitor- CPU, Chassis, CPU Optional/Water Pump temperature sensing
  - CPU, Chassis, CPU Optional/Water Pump Fan Tachometer
  - CPU, Chassis, CPU Optional/Water Pump Quiet Fan (Auto adjust chassis fan speed by CPU temperature)
  - CPU, Chassis, CPU Optional/Water Pump Fan multi-speed control
  - Voltage monitoring: +12V, +5V, +3.3V, CPU Input Voltage, CPU Internal Voltages
• Form Factor- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
  - 8 Layer PCB
  - 4 x 2oz Copper
• OS- Microsoft®Windows®10 64-bit / 8.1 64-bit / 8 64-bit / 7 32-bit / 7 64-bit
• Certifications- FCC, CE
  - ErP/EuP ready (ErP/EuP ready power supply is required)
