we specialize in computer accessories and so on. it is original parts please buy with confidence.Description
2x sata cable(free gift).
1 xI/O back panel.
The above pictures are for reference only.
itemintroduction
CPU
- Supports 9th and 8th Generation Intel® Core™ Processors (Socket 1151)
- Supports CPU up to 95W
- 4-phase power supply design
- Supports Intel® Turbo Boost 2.0 Technology
Chipset
-Intel® H310
RAM
- Dual channel DDR4 memory technology
- 2 x DDR4 memory slots
- Supports DDR4 2666 / 2400 / 2133 (non-ECC), un-buffered memory
- Maximum system memory capacity: 32GB*
- Supports Intel® Extreme Memory Profile (XMP) 2.0 technology
- DIMM sockets feature 15µ gold plated headers
*Due to operating system limitations, the actual memory that can be used under Windows® 32-bit operating system will be less than 4GB. Using a 64-bit CPU under Windows® 64-bit operating system does not have this limitation.
BIOS
- Multilingual 128Mb AMI UEFI Legal BIOS with GUI support
- Compliant with ACPI 6.0 Compliant Wake Events
- Support SMBIOS 2.7
- CPU, GT_CPU, DRAM, PCH 1.05V Voltage Multifunction Regulator
Onboard graphics card
- Supports Intel® UHD graphics built-in visual technologies: Intel® High Speed Video Sync Technology (AVC, MVC (S3D) and MPEG-2 Full HW Encode1), Intel® InTru™ 3D, Intel® Clear Video Technology, Intel® Insider™, Intel® UHD Graphics Chip
- DirectX 12
- HWA Encode/Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (decode only), MPEG2, MJPEG, VC-1
- Three display output options: D-Sub, DVI-D and HDMI**
- Supports HDMI 1.4 technology, up to 4K x 2K (4096x2160) @ 30Hz resolution
- Support DVI-D, maximum resolution up to 1920x1200 @ 60Hz
- Supports D-Sub, up to 1920x1200 @ 60Hz
- Supports HDMI 1.4 port auto-sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) (requires HDMI compatible monitor)
- Supports HDCP 2.2 functionality via DVI-D and HDMI 1.4 ports
- Supports 4K Ultra HD (UHD) playback via HDMI 1.4 port
*Only processors with built-in GPU can support Intel® UHD graphics chip built-in visual technology and display output.
**Supports up to two monitors at the same time
Sound effect
- 7.1 channel high definition audio (Realtek ALC887 audio codec)*
- Support anti-surge
- ELNA Professional Audio Capacitors
*To configure 7.1-channel high-definition audio, use the front panel audio module and enable multi-channel audio through the audio driver.
local area network
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY Intel® I219V
- Support Wake-On-LAN function
- Support anti-lightning/anti-ESD static electricity
- Supports Energy Efficient Ethernet 802.3az
- Support PXE
Expansion slot
- 1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode)*
- 2 x PCI Express 2.0 x1 slots
*Support NVMe SSD boot
Storage
- 4 x SATA3 6.0 Gb/s ports, support NCQ, AHCI and hot plug*
- 1 x M.2 port (M2_1), supports M Key 2230/2242/2260/2280 type M.2 SATA3 6.0 Gb/s and M.2 PCIe module to Gen2 x4 (20 Gb/s)**
*If M2_1 is occupied by a PCIE-type M.2 device, SATA3_3 will be disabled.
**Support NVMe SSD boot
Support ASRock U.2 kit
Onboard interface
- 1 x Printer Port Header
- 1 x COM port header
- 1 x TPM header
- 1 x Chassis open warning function header and speaker header
- 1 x CPU Fan Connector ((4-pin))*
- 2 x Chassis/Water Pump Fan Connectors ((4-pin)) (Smart Fan Speed Control)**
- 1 x 24-pin ATX power connector
- 1 x 8-pin 12V power connector
- 1 x front panel audio jack
- 2 x USB 2.0 pin headers (supports 4 USB 2.0 ports) (supports ESD protection)
- 1 x USB 3.1 Gen1 header (supports 2 USB 3.1 Gen1 ports) (supports ESD protection)***
*CPU fan connector supports up to 1A (12W) power supply.
**The case/water pump fan supports up to 2A (24W) water cooling fan.
CHA_FAN1/WP and CHA_FAN2/WP can automatically detect 3-pin or 4-pin fans.
***USB_11_12 interface shares resources with USB_9_10 interface
I/O port on the rear panel
- 1 x PS/2 keyboard/mouse port
- 1 x D-Sub connector
- 1 x DVI-D port
- 1 x HDMI port
- 4 x USB 2.0 ports (supports ESD protection)
- 2 x USB 3.1 Gen1 ports (supports ESD protection)
- 1 x RJ-45 network interface with indicator lights (action/connection indicator and speed indicator)
- HD Audio Jack: Line In / Front / Mic
Dimensions
- Micro ATX : 8.9-in x 7.4-in, 22.6 cm x 18.8 cm
Operating system
- Supports Microsoft® Windows 10 64-bit / 11 64-bit
