Features11ac WiFi Router combines universal IoT HUB (2.4G/5GHz WiFi, Zigbee, Infrared)Single APP to manager multiple X10, multiple sensors & Philips HUE with cross control. (If-Then Rules, Scenes can be defined by user)Containing 3 different Cloud services (P2P with AES128 Encryption, IoT, Infrared support list database)Transnational Remote Control which can provide more flexible and convenience user experience. (IoT control, Storage upload/download)
Package Contents ASRock AC1300 IoT Wireless RouterRouter Quick Installation GuidePower AdapterRJ-45 Ethernet CableHardware Parameters 802.11a/b/g/n/ac Wireless StandardQualcomm Quad-Core A7 Processor400Mbps 2.4GHz + 867Mbps 5GHz SpeedExternal 5 dBi High Gain Antennas (WiFi) x 2Gigabit WAN Port x 1, LAN Port x 4USB 3.0 Port x 1, USB 2.0 Port x 1 for StorageIR Learning and List Mode Remote ControlZigbee Radio for IoT ApplicationsSoftware Features WiFi protected access WPA/WPA2-AESIoT remote control through APPSupports MU-MIMO and beamformingL2TP/IPSec and OpenVPN VPN server supportParental control for children protectionGuest SSID network accessPeriodically reboot self-healing functionIoT Geo-fence automatically activeUSB data accessSystem Requirement Microsoft Windows 7, 8, 10iOS 8.1 or laterAndroid 4.2 or laterDimensions 210 x 137.51 x 43 mm (w/o Antenna)210 x 160.51 x 186.72 mm (w Antenna)Weight 440 gWireless Standard 802.11a/b/g/n/acFrequency Band 2.4GHz, 5GHz SimultaneousWAN Ethernet Port 1 x RJ45 10/100/1000 WAN PortLAN Ethernet Ports 4 x RJ45 10/100/1000 WAN PortUSB Port USB 3.0 x1, USB 2.0 x1Wireless Speed 2.4GHz: 500 Mbps5GHz: 800 MbpsWireless Security WPA, WPA2,Mixed, WPSWireless Antennas 2 x internal high performance antennas1 x sub-giga antenna (option)Power Source Output: 12V DC / 1.5APower Source 1 YearOperating temperature 0° to 40° (32° to 104° F)Operating humidity 90% maximum relative humidity, noncondensingCertification FCC, CE, VCCI, IC, BSMI
Product DetailsBrand: ASRockSKU: B074PXNRFQModel: X10MPN: X10EAN: 4717677330922
