Key Features

Half- and full-duplex operation

Transparent to IEEE 802.1Q packets

Rack mountable using optional AT-MCR12, AT-TRAY4 or AT-TRAY1chassis

Wall mountable using AT-WLMT

Auto MDI/MDI-X

Missing Link

Link test

RoHS compliant

Technical Specifications

Status Indicators Power: Indicates power is applied to the converter Link (2): Indicates a valid receive link exists Activity (2): Indicates TX/RX on the port FDX: Indicates full-duplex operation (MC104XL only) ML: Indicates Missing Link Switches ML - link Test: Enable Missing Link A/N: Enable auto-negotiation Packet Transmission Characteristics Round trip delay: 0.4µs maximum Bit Error Rate (BER): <10-12 Power Characteristics External power supply 120V AC, 60Hz (US model) 240V AC, 50Hz (European models) Input supply voltage 12vDC Max current 500mA Power consumption 6W Environmental Specifications Operating temperature 0ºC to 40ºC (32°F to 104°F) Relative humidity 5% to 95% (non-condensing) Storage temperature -20ºC to 80ºC (-4°F to 176°F) Operating altitude 0 to 10,000 feet Physical Characteristics Dimensions (W x D x H) 10.5 cm x 9.5 cm x 2.5 cm (4.12 in x 3.75 in x 1.0 in) Weight: 294 g (10.4 oz) Electrical/Mechanical Approvals EMC FCC Class A (MC104XL) EMC FCC Class B Safety compliant UL-Cul, CSA/CSA, NRTL, TUV, CE
