Asus Prime H610I-PLUS-CSM Desktop Motherboard - Intel H610 Chipset - Socket LGA-1700 - Mini ITX (primeh610i-plus-csm) Asus Prime H610I-PLUS-CSM Desktop Motherboard - Intel H610 Chipset - Socket LGA-1700 - Mini ITX (primeh610i-plus-csm)

International Customers: All electronic products are packaged for sale in the US with US voltage.

Package Contents: PRIME H610I-PLUS-CSM Desktop Motherboard 2 x SATA 6Gb/s Cables 1 x I/O Shield 1 x Screw Package for M.2 SSD 1 x Vertical M.2 Key E Bracket Set 1 x User Guide

Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Brand Compatibility: Intel

Product Description

This item is brand-new, factory sealed.

PRIME H610I-PLUS-CSM

Intel LGA 1700 socket: Ready for 14th, 13th & 12th Gen Intel Core processors.

Enhanced power solution: 5+1+1 DrMOS power stages for stable power delivery.

Comprehensive cooling: VRM heatsink, PCH heatsink and Fan Xpert.

Ultrafast connectivity: 32Gbps M.2 slot, Intel 1 Gb Ethernet and USB 3.2 Gen 1 ports.

5X Protection III: Multiple hardware safeguards for all-round protection.

Remote management Software: ASUS Control Center Express (ACCE) for easier IT endpoint managementCPU
Intel Socket LGA1700 for 13th Gen Intel CoreTM
Processors and 12th Gen Intel CoreTM, Pentium Gold and Celeron Processorsnote1
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0note2
Note1: Refer to for CPU support list.
Note2: Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.Chipset
Intel H610 ChipsetMemory
2 x DIMM, Max. 96GB, DDR5 5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memorynote
Dual Channel Memory Architecture
Supports Intel Extreme Memory Profile (XMP)
Note: Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit /> Note: Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.Graphics
1 x DisplayPortnote2
1 x VGA port
1 x HDMITM portnote3
Note1: Graphics specifications may vary between CPU types. Please refer to for any updates.
Note2: Supports max. 4K at 60Hz as specified in DisplayPort 1.4.
Note3: Supports 4K at 60Hz as specified in HDMI 2.1.Expansion Slots
Intel 13th and 12th Gen Processors
1 x PCIe 4.0 x16 slotStorage
Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports
Intel H610 Chipset
M.2 slot (Key M), type 2260/2280 (supports PCIe 3.0 x4 mode)
4 x SATA 6Gb/s portsEthernet
1 x Intel 1Gb Ethernet
ASUS LANGuardWireless and Bluetooth
M.2 slot only (Key E, CNVi and PCIe) note
Note: Wi-Fi module is sold separately.USB
Rear USB (Total 4 ports)
2 x USB 3.2 Gen 1 (5G) ports (2 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
Front USB (Total 4 ports)
1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports
1 x USB 2.0 header supports 2 additional USB 2.0 portsAudio
Realtek 7.1 Surround Sound High Definition Audio CODECnote
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Dedicated audio PCB layers
Note: A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.Back Panel I/O Ports
2 x USB 3.2 Gen 1 (5G) ports (2 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
1 x DisplayPort
1 x VGA port
1 x HDMITM port
1 x V-M.2 slot (Key E)
1 x Intel 1Gb Ethernet port
3 x Audio jacks
1 x PS/2 Keyboard/Mouse combo portInternal I/O Connectors
Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin Chassis Fan header
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage related
1 x M.2 slot (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 1 (5G) header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 header supports 2 additional USB 2.0 ports
Miscellaneous
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x Mono-out header(with Amp IC)
1 x SMBUS header
1 x Speaker header
1 x SPI TPM header (14-1pin)
1 x 10-1 pin System Panel headerSpecial Features
ASUS 5X PROTECTION III
- DIGI+ VRM
- LANGuard
- Overvoltage Protection
- SafeSlot Core
- Stainless-Steel Back I/O
ASUS Q-Design
- Q-DIMM
- Q-LED (CPU (red), DRAM (yellow), VGA (white), Boot Device (yellow green))
- Q-Slot
ASUS Thermal Solution
- Aluminum heatsink designSoftware Features
ASUS Exclusive Software
Armoury Crate
AI Suite 3
- Performance And Power Saving Utility
TurboV EVO
EPU
DIGI+ VRM
Fan Xpert
ASUS CPU-Z
Norton 360 Deluxe (60 Days Free Trial)
WinRAR (40 Days Free Trial)
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ ModeBIOS
128 Mb Flash ROM, UEFI AMI BIOSManageability
WOL by PME, PXEAccessories
Cables
2 x SATA 6Gb/s cables
Miscellaneous
1 x I/O Shield
1 x Screw package for M.2 SSD
1 x Vertical M.2 Key E bracket set
Documentation
1 x User guideOperating System
Windows 11 64-bit, Windows 10 64-bitForm Factor
Mini ITX Form Factor
6.7 inch x 6.7 inch ( 17.02 cm x 17.02 cm )Item Dimension (L inchxW inchxH inch)
9 x 8 x 3

Weight
2.00lb

Warranty Information
3 Years SpecificationPhysical CharacteristicsForm FactorMini Warranty3 YearI/O ExpansionsTotal Number of Expansion Slots1PCI Express StandardPCI Express 4.0Number of PCI Express x16 Slots1Total Number of PCI Express Slots1MemoryMemory TechnologyDDR5 SDRAMNumber of Memory Slots2Memory Speed Supported

• 5600 MHz
• 5400 MHz
• 5200 MHz
• 5000 MHz
• 4800 MHz

Memory Form Factor

• 14th Gen
• 13th Gen
• 12th Gen

Processor Supported

• Pentium Processor Supported1Processor SocketSocket LGA-1700Chipset ModelH610Onboard InterfacesNumber of SATA Interfaces4Total Number of Onboard USB Ports4Number of M.2 Interfaces1Number of Onboard USB 2.0 Ports2Interfaces/PortsVGAYesHDMI Version 2.1 DisplayPortYesHDMIYesTotal Number of USB Ports4Number of USB 3.2 Gen 1 Type-A Ports2Number of Network (RJ-45) Ports1I/O ControllerController TypeSerial ATA/600VideoOnboard VideoCPU Dependent VideoNetwork & CommunicationGigabit EthernetYesAudioAudio Channels7.1 Shipping
