for All Products Aten KH2508A 2-Console 8-Port Cat 5 KVM Switch with Daisy-Chain Port Manufacturer:Aten SKU:KH2508A Condition:New Warranty:1 Year
The KH2508A KVM switch is a control unit that allows IT administrators to access and control multiple computers from two PS/2 or USB KVM consoles (one bus). Operators working at up to two consoles can independently and simultaneously take control of up to 8 computers. By daisy chaining up to 15 additional switches, as many as 128 computers can be controlled from the original KVM consoles. This switch has been designed with unique and powerful features that enable administrators to manage their entire server room and data center devices easily and conveniently.
For example, the advanced Adapter ID feature stores the Adapter Cable"s configuration information – such as its ID, port name, OS, keyboard language, etc. This feature allows administrators to relocate servers to different ports without having to reconfigure the adapters . Other advances found with these switches includes enhanced video quality – extending the distance to the servers to up to 50 m at a resolution of 1280 x 1024.*With KVM Adapter Cable KA7000 series A KH2508A installation provides one of the best, and most economical, solutions ATEN offers to the SMB market. There is no better way to save time, space, and money than with a KH2508A KVM switch.
- Two KVM consoles independently and simultaneously control up to 8 directly connected computers
- By daisy chaining up to 15 additional KH2508A switches, as many as 128 computers can be controlled from the original KVM console
- Console conversion – any type of KVM console can control any type of computer; mixed combinations (PS/2&USB) supported on both the KVM console and computer sides
- Superior Video Quality- Supports the video resolutions up to 1600x1200 at 60Hz for up to 40 meters, and 1280x1024 at 75 Hz for up to 50 meters *With KVM Adapter Cable KA7000 series
- OSD Backup/Restore feature – enables the administrator to back up the switch"s configuration and user profile information
- Configure port access rights for users on a port - by - port basis
- Diversified port operation mode enables flexible computer management – Occupy, Exclusive and share modes
- Three port selection methods: Manual (via front panel pushbuttons), Hotkey, and multi-language OSD (On Screen Display)
- Multiplatform support – PC, Mac, Sun, and serial
- Multiple User Accounts -Supports up to 10 user and 1 administrator accounts
- Two-Level Password Security – Supports one administrator and ten user profiles. Password protection prevents unauthorized accessing to the installation
- Auto Scan mode enables continuous monitoring of user-selected computers
- Broadcast Mode sends commands from the console to all computers – allowing you to perform operations (such as software installation, upgrades, shutdowns, etc.), on them simultaneously
- Adapter ID
- Firmware Upgradeable
Specifications:
Computer Connections Direct 8 Maximum 128(via Daisy-chain) Port Selection OSD, Hotkey, Pushbutton Connectors Console Ports 4 x USB Type A Female (White) 2 x 6-pin Mini-DIN Female (Purple) 2 x 6-pin Mini-DIN Female (Green) 2 x HDB-15 Female (Blue) KVM Ports 8 x RJ-45 Female Daisy Chain Ports 1 x DB-25 Female (Black) 1 x DB-25 Male (Black) Firmware Upgrade 1 x RJ-11 Female Power 1 x IEC 60320/C14 Switches Port Selection 8 x Pushbutton Console Selection 2 x Pushbutton Reset 1 x Semi-recessed Pushbutton Firmware Upgrade 1 x Slide Power 1 x Rocker LEDs Online 8 (Green) Selected 8 (Orange) Console 2 (Orange) Power 1 (Blue) Station ID 1 x 7-segment LED display (Orange) Emulation Keyboard / Mouse PS/2; USB Scan Interval 1-255 Seconds Video 1600 x 1200 at 60 Hz (40m); 1280 x 1024 at 75 Hz (50m) Maximum Input Power Rating 100–240 VAC; 50/60 Hz; 1A Power Consumption 120V/7.2W; 230V/8.6W Environmental Operating Temperature 0-50°C Storage Temperature -20-60°C Humidity 0-80% RH, Non-condensing Physical Properties Housing Metal Weight 2.81 kg ( 6.19 lb ) Dimensions (L x W x H) 43.72 x 15.58 x 4.40 cm (17.21 x 6.13 x 1.73 in.)
Package Includes:
1x KH2508A Cat 5 High-Density KVM Switch 1x Firmware Upgrade Cable 1x Power Cord 1x Rack Mount Kit 1x Foot Pad Set (4 pcs.) 1x User Instructions
