Enterprise Testing Conditions
Threat Prevention (Mbps)1450
Next Generation Firewall2800
IPS Throughput (Mbps) 900
Firewall Throughput (Mbps)1,000
RFC 3511, 2544, 2647, 1242 Performance (LAB)
Firewall 1518 Byte UDP Packets (Mbps) 2,000
VPN AES-128 Throughput(Mbps)1,300
Connections per Second14,000
Concurennt Connections500,000
Software
SecurityFirewall, VPN, User Awareness, QoS, Application Control, URL Filtering, IPS, Anti-Bot, Antivirus, Anti-Spam and SandBlast Threat Emulation (sandboxing)
Unicast, Multicast RoutingOSPFv2, BGPv4 and 4++, RIP, PIM (SM, DM, SSM), IGMP
Mobile Access License (Users)100 remote SNX or Mobile VPN client users
Hardware
WAN Port1x 10/100/1000Base-T RJ-45 port
LAN Port5x 10/100/1000Base-T RJ-45 ports
Radio Band (association rate)One radio band non-concurrent: 2.4GHz (max 450 Mbps) or 5GHz (max 1,300 Mbps)
Console Port1x USB-C
USB Port1x USB 3.0
Dimensions
EnclosureDesktop, wall mount
Dimensions (W x D x H) 210 x 160 x 37.5 mm, 8.3 x 6.3 x 1.5 in.
Weight 0.43 kg (0.95 lbs.)
Environment
Operating / Storage0ºC ~ 40ºC / -45ºC ~ 60ºC (5~95%, non-condensing)
Power Requirements
AC Input110 – 240VAC, 50 – 60 Hz
Power Supply Rating12V/3.3A 40W power adapter
Certifications
Safety/Emissions/Environment UL/c-UL 62368-1 , IEC 62368-1 CB | EMC, EMI EN55024, EN55032 Class B, VCCI, AS, NZS CISPR 32, IC ICES 03, RSS247, FCC: Part 15 Class B, C, E | RoHS, REACH, WEEE
