Cisco ASR1006-X ASR 1000 6RU 100Gbps Modular WAN Router Chassis – 5 Star Certified Refurb

Condition: 5 Star Certified Refurbished. Hardware Honcho's highest refurbishment tier — professionally inspected, tested, and restored to like-new condition. Cosmetically excellent with no significant wear. Fully functional and ready to deploy.

Product Overview

The Cisco ASR1006-X is a high-performance 6-rack-unit (6RU) modular chassis from the Cisco ASR 1000 Series Aggregation Services Routers — purpose-built for medium to high-end enterprise WAN aggregation, Internet edge routing, data center interconnect, and service provider edge deployments requiring up to 100 Gbps system bandwidth with carrier-grade high availability. The most flexible chassis in the ASR 1000 X-Series, the ASR1006-X features 2x ESP slots supporting up to 100 Gbps Embedded Services Processors, 2x route processor slots for 1:1 RP redundancy, 2x SIP slots supporting up to 8 SPA slots, 4x Ethernet Port Adapter (EPA) slots, and dual redundant power supply support — delivering the scalability, interface density, and redundancy required for mission-critical network infrastructure.

Supporting 10G, 40G, and 100G Ethernet interfaces through compatible ESP, SPA, and EPA modules, front-to-back airflow, N+1 power redundancy, and Cisco IOS XE with open APIs including RESTCONF/NETCONF — the ASR1006-X is a proven and future-ready platform for demanding enterprise and service provider deployments. Compatible with ASR1000-RP2, ASR1000-RP3, ASR1000-ESP40, ASR1000-ESP100, ASR1000-SIP40, and ASR1000X-AC-1100W power supplies.

• Model: ASR1006-X
• Series: Cisco ASR 1000
• Device Type: 6RU Modular Router Chassis
• Maximum System Bandwidth: Up to 100 Gbps
• Maximum IPSec Throughput: 29 Gbps
• ESP Slots: 2x (supports ASR1000-ESP40 or ASR1000-ESP100)
• Route Processor Slots: 2x (supports ASR1000-RP2 or ASR1000-RP3)
• SIP Slots: 2x (supports ASR1000-SIP40)
• SPA Slots: Up to 8x (via SIP modules)
• EPA Slots: 4x Ethernet Port Adapter slots
• Power Supply: Dual redundant — option of 1100W AC or 950W DC (sold separately)
• Maximum Power: 4,500W AC / 4,600W DC max
• Airflow: Front-to-back
• Fan Trays: Dual hot-swappable fan trays
• Input Voltage: 85–264V AC (worldwide ranging) or -40 to -72V DC
• Form Factor: 6U Rack-mountable
• Operating System: Cisco IOS XE
• Management: IOS XE CLI, Cisco Prime Infrastructure, RESTCONF/NETCONF open APIs
• Routing: OSPF, EIGRP, BGP, IS-IS, MPLS LDP
• Compliance: NEBS, ETSI, UL60950-1, EN 60950-1, IEC 60950-1
• Ideal for: WAN aggregation, Internet edge routing, data center interconnect, SP edge, hybrid cloud, IWAN, secure WAN
• Features: 100 Gbps max, dual RP redundancy, dual ESP, 8 SPA slots, 4 EPA slots, N+1 power, front-to-back airflow, NEBS compliant, IOS XE, RESTCONF/NETCONF

Physical Specifications

• Dimensions: 10.47 × 17.2 × 18.15 in (265.9 × 437.4 × 461.0 mm)
• Weight: Approx. 36.50 lbs (16.6 kg) — chassis only without modules
• Form Factor: 6U Rack-mountable
• Operating Temperature: 32–113°F (0–45°C)

Included Accessories

• Cisco ASR1006-X chassis
• Rack mounting hardware (as available)

Important Notes

• Chassis only — no modules included. The ASR1006-X ships as a base chassis. Route Processors (ASR1000-RP2/RP3), Embedded Services Processors (ASR1000-ESP40/ESP100), SIP modules (ASR1000-SIP40), EPA modules, SPA modules, and power supplies are all sold separately.
• Power supplies not included — requires ASR1000X-AC-1100W (AC) or ASR1000X-DC-950W (DC) power supplies, sold separately. A mix of AC and DC power supplies is not supported.
• ASR1006-X vs ASR1006 (non-X): The ASR1006-X supports 100 Gbps per slot bandwidth and EPA slots for 40G/100G Ethernet port adapters — the non-X ASR1006 is limited to 40 Gbps per slot with no EPA support. The -X chassis requires ASR1000X power supplies (not interchangeable with non-X chassis PSUs).
• ASR1006-X vs ASR1009-X: The ASR1009-X is a 9-slot chassis supporting higher port density — choose the ASR1009-X for maximum SPA/EPA slots. The ASR1006-X offers 6 slots in a more compact 6RU footprint.
• IOS XE Software Release 3.16.0 minimum required for ASR1006-X.

Hardware Honcho 5 Star Certified Refurbished Assurance

• ⭐⭐⭐⭐⭐ Hardware Honcho's highest refurbishment tier — like-new condition
• Professionally inspected, tested, and restored to full working condition
• Cosmetically excellent — no significant scratches, dents, or wear
• Verified authentic Cisco hardware
• Carefully packaged for secure shipment
• Fast shipping with professional handling

The Cisco ASR1006-X delivers up to 100 Gbps modular WAN aggregation, dual RP and ESP redundancy, 8 SPA slots, 4 EPA slots, N+1 power, NEBS compliance, and full IOS XE intelligence — a proven and highly flexible 6RU chassis for enterprise WAN edge, Internet gateway, data center interconnect, and service provider edge deployments.
