Cisco Meraki MS150-48FP-4X (CLAIMED)
Devices are claimed!Overview

The Cisco Meraki MS150-48FP-4X is a cloud‑managed, stackable Layer 2 access switch designed for branch and campus deployments. It provides 48 PoE+ ports plus 4 x 10 GbE SFP+ uplinks in a 1U rack‑mountable chassis with a 740 W PoE budget, making it well‑suited for Wi‑Fi, surveillance, VoIP, and IoT access networks.

Port configuration

• 48 x 10/100/1000 Mbps Gigabit Ethernet RJ‑45 ports (PoE/PoE+).
• 4 x 10 Gbps SFP+ uplink ports for high‑speed aggregation.
• Non‑blocking backplane with 176 Gbps switching capacity.
• 2 dedicated stack ports providing 80 Gbps total stacking bandwidth (cables sold separately).

Power and PoE

• PoE budget up to 740 W with PoE+ (802.3at/802.3bt) support per port (up to 30 W typical).
• Perpetual PoE keeps endpoints powered during reboots and upgrades.
• Dynamic power allocation across 48 ports for APs, phones, cameras, and other PoE‑powered devices.

Management and features

• Fully managed via the Cisco Meraki Dashboard (cloud‑based).
• Automatic cloud firmware upgrades and configuration sync.
• Remote packet capture tools accessible from the Dashboard.
• Layer 2 switching with 802.1q VLAN tagging, ACL support, broadcast storm control, and 802.1X authentication.
• Dynamic ARP inspection and DHCP snooping for security.
• Support for Adaptive Policy when using an Advanced license.
• Static routing capability (enabled via software feature roadmap).

Physical and deploymentForm FactorRack‑mountable, 1UPort Density48 RJ‑45 Ethernet + 4 x 10G SFP+Switching Capacity176 GbpsStacking2 stack ports, up to 8 switches in a stackPower SupplyInternal AC 100–240 VManagementMeraki Dashboard (cloud)MonitoringSNMP, Syslog integration
