Printing Method
Direct Thermal printing
Printing Speed (Max.)
up to 4 inches/sec
Print Density
Adjustable with software (not included)
Fonts
1 Scalable, 8 Bitmap, OCR-A & B
True type Download
Supported Standard
Control Language
Conforms to Datamax? programming language
Media Type
Roll or Fanfold; Continues or Perforated; die cut labels; Tags & Tickets
Media Sensing
Label Gap, notch or reflective
Resolution/Dot pitch
203 dpi, 8 dots/mm
Media width (Min-Max)
19 - 118 mm
0.75 - 4.65 inches
Media Roll Size (Max)
125 mm, 5 inches (Internal);
Media Thickness
(Min-Max)
0.0635 - 0.254 mm
0.0025 - 0.01 inches
Printing width (Max)
104 mm
4.1 inches
Printing lenght (Max)
812 mm
32 inches
Label length (Min)
2.54 mm
0.1 inches
Bar-code Symbologies
Code39, Code93, ITF, Codabar, UPC-A/E, EAN-8/13, UPC and EAN 2 and 5-digit extensions, Plessey, Postnet, Interleaved 2 of 5, Code128 with subsets A/B/C and UCC Case Codes, Telepen, FIM & HIBC.
2D Codes: PDF-417, Maxi Code, Datamatrix & QR style="margin-right:2px; margin-left:2px">
Memory
DRAM
8 Mb
Flash Memory
2 Mb
Weight
3.6 Kg
External Dimensions
(W x D x H)
231 x 289 x 183 mm
