D-Link DEM-432XT SFP+ Module - 1 x LC Duplex 10GBase-SR Network10 (DEM432XT) D-Link DEM-432XT SFP+ Module - 1 x LC Duplex 10GBase-SR Network10 (DEM432XT)

International Customers: All electronic products are packaged for sale in the US with US voltage.

Compatibility: MSA Compliant

Country of Origin: China

Product Description

This item is brand-new, factory sealed.

Cost-effective solution for 10G fiber connection
Small form factor, allowing higher port densities for 10G connections
Lower power with Ethernet 802.3ae
Compliant with fiber MSA (Multiple Source Agreement)
D-Links 10G SFP+ Module series are hot-swappable SFP+ transceivers that plug into SFP+ slots on switches and support 10G Ethernet. The D-Link 10GBASE SFP+ Module Series transceivers offer customers a wide variety of 10G Ethernet connectivity options for data centers, enterprise wiring closets, and service provider transport applications. Enhanced Small Form-factor Pluggable FormatThe transceivers use the Enhanced Small Formfactor Pluggable format (SFP+). The SFP+ form factor is smaller than other form factors such as Xenpak, X2, and 10G XFP, ensuring lower costs, lower power disruption, and higher port density. They provide the necessary signal amplification for data to be transmitted to the network cable from the port, and vice versa, for the port to receive data from the network cable. Hot PluggableAll D-Link transceivers are hot-pluggable. You can connect a transceiver while the system is powered on without causing any problems. This permits modules to be added or removed without interrupting the network. 10G Ethernet speedsThe transceivers all support 10G Ethernet, which results in very fast data transmissions of up to 10 Gbit/s. This is 10 times faster than Gigabit Ethernet and enables the switch to handle faster and higher data transmissions, making it very suitable for business needs.Features
Hot Pluggable
MSA Compliant
RoHS Compliant
Standards
Compliance with IEEE802.3ae, 10GBASE-LR
Form Factor Type: SFP+
Fibre Channel FC-PI standard: 1200-SM-LL-L
Fiber Media support: Single-Mode
Distance Capacity: 10Km
Speed
10Gbps
Interface
Duplex LC Connector
Single-direction
Wavelength: 1310nm
Output (TX) Optical Power
MAX.: +0.5 dBm
MIN.: -8.5 dBm
Input (RX) Optical Power
MAX.: +0.5dBm
MIN.: -12.6 dBm
Sensitivity: -12.6 dBm
Cable Type: single-mode 9/125um fiber
Operating
Power: 3.3V
Max Input Current at 3.3V: 300mA
Power Budget
MIN: 4.1dB
MAX: 13.1dB
Heat Generated 3.6KJ/H
Reliability
MTBF (Hours) 4,650,000
Physical and Environment
Operation Temperature: 0o-70oC
Storage Temperature: -40o-85oC
Operating Humidity: 5% - 85%
Storage Humidity: 5% - 95%
Bail latch color: Blue
Emission (EMI) and Safety Certifications
EMI: CE, FCC, VCCI
Safety: UL, TUV, CDRH
Item Dimension (L inchxW inchxH inch)
6 x 3 x 2Weight
1.00lbWarranty Information
2 Years SpecificationPhysical CharacteristicsForm FactorHot-pluggableWeight (Approximate)0.04 Warranty2 YearInterfaces/PortsTotal Number of Ports1Connector TypeLCInterfaces/Ports Details1 x LC Duplex 10GBase-SR NetworkGeneral InformationBrand NameD-LinkMarketing Information D-Link's 10G SFP+ Module series are hot-swappable SFP+ transceivers that plug into SFP+ slots on switches and support 10G Ethernet. The D-Link 10GBASE SFP+ Module Series transceivers offer customers a wide variety of 10G Ethernet connectivity options for data centers, enterprise wiring closets, and service provider transport applications. Enhanced Small Form-factor Pluggable Format The transceivers use the Enhanced Small Formfactor Pluggable format (SFP+). The SFP+ form factor is smaller than other form factors such as Xenpak, X2, and 10G XFP, ensuring lower costs, lower power disruption, and higher port density. They provide the necessary signal amplification for data to be transmitted to the network cable from the port, and vice versa, for the port to receive data from the network cable. Product TypeSFP+Product NameDEM-432XT SFP+ ModuleManufacturerD-Link Systems, IncManufacturer Part NumberDEM-432XTProduct ModelDEM-432XTMedia & PerformanceEthernet Technology10 Gigabit EthernetMedia Type SupportedOptical FiberFiber Mode SupportedSingle-modeNetwork Technology10GBase-SRTitleProduct TitleD-Link DEM-432XT SFP+ Module (DEM432XT)Technical InformationApplication/Usage
