Digi XBee® (Zigbee®, DigiMesh®, 802.15.4), Bluetooth® 5.0 and RS-232/485 for connection to local devicesOpen source Python environment for custom application developmentLTE Cat 4 cellular and 10/100 Ethernet WAN connectivityDigi Remote Manager® platform for easy setup, mass configuration/firmware updates, remote device management and out-of-band managementFull-featured industrial cellular routing platformRedundant connectivity with dual SIMs and Digi SureLink®Built-in Digi TrustFence® for device security, device identity and data privacySPECIFICATIONSDigi IX15DIGI XBEE®XBEE MODULEStandard: Digi XBee® 3 Zigbee® 3.0 MMT (XB3-24Z8UM-J)
PRO: Digi XBee® 3 PRO Zigbee® 3.0 MMT (XB3-24Z8UM)ZIGBEE STACKZigbee® Standard and Zigbee® PRO versions availableZIGBEE TRANSMIT POWERStandard: 6.3 mW (8 dBm); PRO: 63 mW (18 dBm)ZIGBEE RECEIVER SENSITIVITY-102 dBmBLUETOOTH® VERSIONSupports BLE 4.2 and capable of interoperating with BLE 5.0 devices that support 1M PHY. Hardware is software upgradable to 5.0 but not yet enabled except payload extensions (future release).XBEE CONNECTOR(1) 50 Ω RP-SMA (center pin: male)CELLULARCERTIFICATIONSVisit Digi's website to checkBANDSLTE Cat 4: B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B28, B38, B39, B40, B41
3G: B1, B2, B4, B5, B6, B8, B19
2G EDGE / GPRS: 850 / 900 / 1800 / 1900 MHzCONNECTORS(2) 50 Ω SMA (center pin: female)SIM SLOTS(2) Mini-SIM (2FF)SIM SECURITYBehind SIM cover, secured with screw (#1 Phillips)SOFTWARE AND MANAGEMENTPYTHONPython 3REMOTE MANAGEMENTDigi Remote Manager; SNMP v2/v3 (user installed/managed)LOCAL MANAGEMENTWebUI (HTTP/HTTPS); CLI (Telnet, SSH)MANAGEMENT / TROUBLESHOOTING TOOLSFTP client, SCP; protocol analyzer with PCAP for Wireshark; event logging with syslog and SMTP client; NTP/SNTP; Nagios, Intelliflow, iPerf, Dynamic DNS, ping, tracerouteETHERNETPORTS(1) RJ-45; 10/100 Mbps (auto-sensing)SERIALPORTS(1) RJ-45 10-pin (10P10C); RS-232/485; software selectable
- RS-232 DTE (RXD, TXD, RTS, CTS, DTR, DCD, DSR, RI)
- RS-485 (TX/RX+; RX/TX-); half-duplexPHYSICALDIMENSIONS (L x W x H)157 mm x 106 mm x 35 mm (6.18 in x 4.17 in x 1.38 in)WEIGHT0.39 kg (0.86 lb)STATUS LEDsPower, SIM, LTE/Internet, XBee, signal strength (5)ENCLOSUREGlass-filled polyphenylene sulphide (PPS) / IP30POWER REQUIREMENTSPOWER INPUT9 - 30 VDC, 1.0 A maximumPOWER CONSUMPTION2.5 W typical (idle); 6 W typical (peak Tx/Rx)ENVIRONMENTALOPERATING TEMPERATURE-40° C to 74° C (-40° F to 165° F); device performance may be impacted above 60° C (140° F)RELATIVE HUMIDITY5% to 95% (non-condensing)APPROVALSCELLULAR AND REGULATORYVisit Digi's website for latest cellular and regulatory approvalsSAFETYUL60950-1, IEC62368-1, CB, EN62311, UL 121201/CSA 213 (Class 1, Div 2)ENVIRONMENTALROHS3EMISSIONS / IMMUNITYCE; RED; FCC Part 15, Subpart B*; ICES-003; AU/NZS CISPR32
