Digigram PCX924 v2 Professional Sound Card • 24-Bit Stereo PCI Audio Interface with S/PDIF & AES/EBU Digital I/O

Product Description

Absolute reliability with great sound. 32bit Drivers for Windows (Including Vista and Seven) available.

The PCX924 stereo sound cards is your best choice for broadcast andother demanding professional audio applications when absolutereliability with great sound is a must. The PCX924 is afull-duplex sound card for simultaneous and independent record andplayback delivering Digigram's famed audio quality and reliability.Embedded DSP handles the audio processing, freeing up the computer'sCPU, minimizing latency and permitting an even greater systemreliability. The PCX924 meets and even surpasses the needs of the mostdemanding professionals, especially in audio production and on-airapplications in Technical slave modeDigital Signal processor56002 at 66 MHzRAM128 kWords (384 kBytes)Size175mm x 99 mmOperating: temp / humidity (noncondensing)0°C/+50°C - 5%/90%Storage : temp / humidity (noncondensing)-5°C/+70°C -0%/95%INPUTS/OUTPUTSAnalog inputs (stereo)1Maximum input level/impedance+22 dBu/ 600 or >10kProgrammable input gaindigital and analogDigital inputs (stereo)1 AES/EBU or SPDIFOther inputsLTC, CD ROM (+8dBu), two GPI (dry contact)Analog outputs (stereo)1 balancedMaximum output level/impedance/td>+22 dBu/low impedance 93 dBDistortion + noise at 1 kHz (record + play)<-90 dB (0.003%)Channel phase difference: 20 Hz/20 kHz< 0.5° / 2°Analog channel crosstalk at 1 kHz<-95 dBDEVELOPMENT ENVIRONMENTSDigigram managementnp SDKOther managementWaveSupported OSWindows 95/98, NT 4.0, 2000, XP, Server 2003
