Item Description

CPU Support

AMD

CPU Socket

sWRX8/sTRX4/TR4/SP3

Screw Type

M3.5

Installation Torque

12.5-15.1 in-lb

Solution

2U Server and Up

Dimensions

119.0 x 79.0 x 65.0 mm

Weight

450g

Material

Aluminum Heatsink with Heatpipe Embedded

Fan Dimension

60 x 60 x 25 mm

Speed

At Duty Cycle 20%: 1600 ± 200 RPM
At Duty Cycle 50%: 4000 ± 10% RPM
At Duty Cycle 100%: 8000 ± 10% RPM

Power

At Duty Cycle 20%: 1.2 W
At Duty Cycle 50%: 2.28 W
At Duty Cycle 100%: 7.2 W

Bearing

Ball Type, Double

Rated Voltage

12V

Air Flow

At Duty Cycle 20%: 8.85 CFM
At Duty Cycle 50%: 21.88 CFM
At Duty Cycle 100%: 43.75 CFM

Noise Level

At Duty Cycle 20%: 18 dBA
At Duty Cycle 50%: 37.9 dBA
At Duty Cycle 100%: 53 dBA

Air Pressure

At Duty Cycle 20%: 0.76 mm-H2O
At Duty Cycle 50%: 4.76 mm-H2O
At Duty Cycle 100%: 19.04 mm-H2O

Lead Wire Pin Out

Pin1- (-)
Pin2- (+)
Pin3- (Techometer/Signal output)
Pin4- (PWM)

Life – Continuous operating

under normal temperature

(40 °C or 104 °F)

70,000 Hours
