CPU SupportAMD®CPU SocketSP7Screw TypeM3.5/M4Installation Torque12.5–15.0 kg-cm (10.8–13.0 in-lbf)Solution1U Server and UpDimensions120.0 x 103.6 x 27.2 mmWeight605 gMaterialCopper Fin + Vapor ChamberFan DimensionØ80 x 13 mmSpeedAt Duty Cycle 20%: 2000 ± 200 RPM
At Duty Cycle 50%: 5900 ± 10% RPM
At Duty Cycle 100%: 10000 ± 10% RPMPowerAt Duty Cycle 20%: 1.44 W
At Duty Cycle 50%: 10.8 W
At Duty Cycle 100%: 42.0 WBearingDouble BallRated Voltage12VAir FlowAt Duty Cycle 0~20%: 7.54 CFM
At Duty Cycle 50%: 17.8 CFM
At Duty Cycle 100%: 26.25 CFMNoise LevelAt Duty Cycle 20%: 7.54 mm-H2O
At Duty Cycle 50%: 41.3 mm-H2O
At Duty Cycle 100%: 118.64 mm-H2OAir PressureAt Duty Cycle 20%: 7.54 mm-H2O
At Duty Cycle 50%: 41.3 mm-H2O
At Duty Cycle 100%: 118.64 mm-H2OLead Wire Pin OutPin#1- Black(-)
Pin#2- Yellow(+)
Pin#3- Green(Tachometer/ Signal Output)Pin#4- Blue (PWM)Life – Continuous operating
under normal temperature
(40 °C or 104 °F)70,000 Hours
