Item Description

CPU Support

Intel® 3rd Gen. Xeon Scalable Processor (code name Ice Lake and Copper Lake)

CPU Socket

FCLGA 4189-4/5(Socket P4/P5)

Screw Type

#8-32

Installation Torque

8 in-lb

Solution

2U Server and Up

Dimensions

113.0 x 82.0 x 66.0 mm

Weight

460 g

Material

Aluminum Fin stack with Heat Pipe embedded

Fan Dimension

60 x 60 x 25 mm

Speed

Up to 8500 RPM

Rated Voltage

12V

Bearing

2 Ball Bearing

Power

At Duty Cycle 0~20%: 1.2 W
At Duty Cycle 50%: 2.52 W
At Duty Cycle 100%: 9.6 W

Air Flow

At Duty Cycle 0~20%: 9.86 CFM
At Duty Cycle 50%: 23.21 CFM
At Duty Cycle 100%: 49.32 CFM

Noise Level

At Duty Cycle 0~20%: 19.3 dBA
At Duty Cycle 50%: 37.9 dBA
At Duty Cycle 100%: 54.3 dBA

Air Pressure

At Duty Cycle 0~20%: 0.86 mm-H2O
At Duty Cycle 50%: 4.76 mm-H2O
At Duty Cycle 100%: 21.5 mm-H2O

Lead Wire Pin Out

Pin#1-Black(-)
Pin#2- Yellow(+)
Pin#3- Green(Tachometer/ Signal Output)
Pin#4- Blue (PWM)

Thermal Grease

Shin-Etsu 7762 or Equivalent

Life – Continuous operating

under normal temperature

(40 °C or 104 °F)

70,000 Hours
