EK-Quantum Velocity² DDC 4.2 PWM D-RGB - 1700 Nickel + PlexiUsed EK-Quantum Velocity² CPU water block, DDC 4.2 PWM pump, reservoir, and pump heatsink combination for Intel LGA1700 systems.
This compact unit combines the major CPU-side components of a custom water-cooling loop into a single assembly.
Condition
The unit is used and shows normal cosmetic wear from previous installation and use, including light surface marks and scratches.
It was previously installed in a custom water-cooling loop in a backup server and was working when removed.The unit was recently disassembled for maintenance, flushed with distilled water, and the O-rings were cleaned and lubricated before reassembly.
Leak-tested after reassembly with no leaks observed.-->Features
EK-Quantum Velocity² LGA1700 CPU water block
Integrated genuine DDC 4.2 PWM pump
Integrated 64 mL reservoir
Nickel-plated copper cold plate
Nickel-plated brass pump heatsink
Clear acrylic middle section
6 x G1/4 ports, including dedicated fill ports
SATA pump power connection
4-pin PWM pump control
5V 3-pin D-RGB connection
14 addressable D-RGB LEDs
Designed for Intel LGA1700 processors
Included
EK-Quantum Velocity² DDC 4.2 PWM D-RGB - 1700 Nickel + Plexi assembly
LGA1700 EK-Exact Mount backplate and mounting hardware
2 mm Allen key
2.5 mm Allen key
Not Included
Thermal paste
Original retail box or packaging
Coolant, tubing, fittings, or other custom-loop components
SpecificationsCPU Socket
Intel LGA1700
Pump
DDC 4.2 PWM
Pump Power
SATA
Pump Control
4-Pin PWM
Reservoir Capacity
64 mL
Ports
6 x G1/4
Lighting
14-LED 5V 3-Pin D-RGB
Dimensions
94.5 x 60.7 x 94.5 mm
EAN / GTIN
3831109897539Please Note
This is a component for a custom liquid-cooling loop. The DDC pump is water-lubricated and should not be operated dry.
Fresh thermal compound will be required for installation.Please review all photos carefully for the exact cosmetic condition and everything included with the sale.
Only the items shown and specifically listed above are included.
