The EVGA X299 Dark motherboard is an enthusiast motherboarddesigned for the high-end destktop (HEDT) high-performance computing (HPC),suitable for casual use, content creation, and gaming. This is an EATX boardwith a 12” x 10.895” form factor, so be sure your case can sufficiently houseit. Undercuts and recesses on the side allow better clearance for IOconnections than other X299 boards. The chipset (LGA 2066) is compatible withIntel 7th-10th gen i7 and i9 Extreme CPUs, offering 4memory slots supporting DDR4 DIMMs with high stability in Dual or Quad Channelmode. Due to its 12-layer PCB and robust 16-phase VRM design (with 2 phasesdedicated to memory), it facilitates stable memory speeds significantly abovestock limits. It can easily push DDR4 clock rates over 4000MT/s, into DDR5territory with stability. Ideal for demanding computing tasks, the EVGA X299Dark motherboard is a reliable choice for enthusiasts.

This was used for design and development work, it has notbeen seriously stressed for benchmarking or other application, but it caneasily handle overclocks. It was paired with an i9 10920X (see other listing)running 128GBs (4x32) of RAM stable. The many PCIe sockets and IO are more thanmost CPU PCI lanes can handle, allowing a lot of flexibility when configuredcorrectly. Personally, the 2 SFF-8639 ports are more reliable for U.2 SSDs thanother EVGA boards in the X299 family, though I did run into compatibility issueswith Dell-branded Gen4 U.2s (which would work at Gen3 speeds). For an i9processor, you can squeeze out almost every bit of IO the board physically haswithout much limitation. Truly an excellent board for the HEDT realm, which hasrecently been coming back to prominence despite the RAMpocalypse.

The bundle is complete including the layout board and otheraccessories, as pictured. Further details can be found on EVGA’s website andother reviews, which I can’t link because of policies. Please feel free to ask any questions.

International buyers accept liability beyond host country, please purchase the appropriate insurance. Shipping options will not be changed to non- providers.

From Newegg:

"The EVGA X299 Dark was built from the ground up to be the best overclocking motherboard on the planel, no compromises."
- Vince "K Ι NGP Ι N" Lucido
Some motherboard companies believe it is enough to tell you that their boards are fast. Others put enough RGB LEDs on their boards to make you think racing lights will make your board go faster. EVGA could have designed a board like those...or it could engineer the X299 Dark - a motherboard line renowned for being the top choice of the world's best overclockers. A motherboard that has already broken 12 World Records...so far:EVGAintroduces you to the ultimate in raw performance for the next-gen Intel®X-Series lineup, theEVGA X299 Dark.The Dark is crafted from the ground up to be the performance apex with everything you need to make a record-breaking benching run or a 24/7 number cruncher, and nothing you don't - a board that is as reliable as it is fast. TheEVGA X299 Darkhas all of the current gen top-tier component support:M.2 SUPPORT2x M.2 Key-M slots / 1x M.2 Key-E slotINTEL®OPTANE™Intel®Optane™ Memory ReadyU.22x U.2 PortsUSBUSB 3.1 Type-A / Type-CSKYLAKE-XUp to 64GB of 4000MHz+ (OC) Quad-Channel RAM on Skylake-XKABY LAKE-XUp to 32GB of 4133MHz+ (OC) Dual-Channel RAM on Kaby Lake-XLAN2x Intel®GbE LAN with teaming supportBIOSEVGA's Full Featured GUI UEFI / BIOSLEGACY LGA20XX SOCKET BACKPLATEAllows for custom CPU cooling solutions (optional)There is much to be said about a beautifully-engineered motherboard designed to handle the highest loads or the most extreme conditions, let alone the rigors and abuse constantly demanded by the best overclockers in the world and still look good doing it. This was achieved, in part, by using:

1. 12-Layer PCB
   12-layer high-speed EATX PCBA with gold-plated shielded edge enhances stability for heavy loads, improved overclocking, and durability for today's extreme cooling hardware.
2. Highly-Efficient 16-Phase PWM
   The X299 Dark features a 16-phase Digital VRM (12 VCore, 1 VSA, 1 VCCIO, 2 Phase Memory PWM) for the cleanest, most stable power design to ensure that you're ready for Intel®'s Core i9 Processors. With this kind of power, the X299 Dark is equipped with dual-fans to maintain optimal VRM temperatures even with watercooled 18-core CPU overclocking.
3. 100% Solid State Capacitors
   The X299 Dark is installed with 100% Solid State Capacitors to ensure a longer lifespan.
4. 300% Higher Gold Content in CPU Socket
   Higher volume of precious metal (300% Gold) used in the sockets greatly improves the conductivity and produces a cleaner signal due to less resistance / impedance.
5. External BCLK / Clock Generators
   An external BCLK controller for fine-tuning KBL-X and SKL-X system performance. and an external clock generator for PCIe stability and performance.
6. 8 SATA Ports - 6 from Intel PCH / 2 from ASM edia ASM 1061
   The X299 Dark features 8 SATA Ports. 2 are supplied by the ASMedia ASM1061, which supports Windows XP for ultimate benching OS flexibility.

7. Triple BIOS Select Switch
   Switch between up to 3 different profiles for overclocking, benching, 24/7 use, or anything you can think of.
8. PCIe Disable Switches
   The X299 Dark offers PCIe disable switches to quickly shut off PCIe slots to troubleshoot or restore used resources without the need to physically uninstall hardware.
9. ProbelT Connector
   Attach your Digital Multimeter to the included ProbelT adapter and monitor your voltages in real-time.
10. PS/2 Port
    Despite the X299 Dark's technical feats, it still features an old school PS/2 keyboard and mouse port to reduce latency and resources for benching and gaming.
11. Creative Core3D Audio
    Creative 5.1 Channel Audio with output amplifiers - the industry standard for audio quality.
12. Intel®VROC Header
    Intel®Virtual RAID On CPU (VROC) header provides support for CPU-attached NVMe RAID.

Although theX299 Darkdoes not featureRGB LED support, it politely reminds you that you can't see pretty in the Dark. This board is engineered for the ultra-enthusiast, including these features:ACTIVE PCH & M.2 COOLINGKeep your SSDs cool under even the longest gaming or benching sessions with the X299 Dark's I/O and expansion slot cover. This cover provides direct airflow over your M.2 devices and exhausts away from the rest of your components.4-WAY SLI SUPPORT4-Way SLI support without the need for PLX chips.

• 4-way SLI support with 44-lane Skylake-X processors
• 3-way SLI support with 28-lane Skylake-X processors
• 2-way SLI support with 16-lane Kaby Lake-X processors

POST INDICATORMulti-Function POST Indicator - Fully configurable in BIOS, these LEDs can be configured to show temperatures, voltages or cycle both in real-time.POST INDICATORVisual Guide / Bench Table - Every EVGA X299 Dark is packed with a printed PCB showing components, LEDs, PCIe lane breakdowns, and other helpful information. More importantly, this PCB doubles as an open-air testing or benching station, providing clearance for heaters, condensation, or even extra power supply storage.PCIe / DIMM STATUS LEDsPCIe / DIMM status LEDs allow for easy system assembly and troubleshooting at a glance.RIGHT ANGLE HEADERS24-pin power, FAN and USB3.0 headers - Hand-crafted design to provide clean system assembly without cable clutter.The X299 Dark proves once again that until you have used it, you don't know the power of the Dark side of the EVGA motherboard lineup.SPECIFICATIONS

• Chipset: Intel®X299
• Socket: Intel®Socket 2066
• Form Factor: EATX
• SLI: 4-Way
• Memory: 4 DIMM Quad-Channel (up to 64GB) DDR4 4000MHz+ (SKX), 2 DIMM Dual-Channel (up to 32GB) DDR4 4133MHz+ (KBL)
• USB: 8 Native USB 3.0 / 4 USB 2.0
• USB 3.1 (rEAR I/O): 1x Type-A, 1x Type-C
• SATA: 6 Native 6.0 Gbps Ports + 2 Legacy ASMedia 6.0 Gbps Ports
• Ethernet: 2x Intel®Gigabit NIC
• Audio: 5.1 Channel Creative Core3D Audio
• Fan Headers: 7 (2 PWM, 5 DC/PWM)
• PCB: 12 Layers

FEATURES

• 300% more gold content in the CPU socket
• 4-Way SLI®Support
• 100% Solid State Capacitors
• Onboard CPU Temp Monitors
• CLEAR CMOS, Power and Reset
• Dual 8 Pin CPU Power
• EVGA Probe-It Connector
• 1x M.2 Key E(32mm) + 2x M.2 Key M (80mm, 110mm)
• Legacy Windows Support, including Windows XP™
• External Clock Gen
