Evolis S10474 Card Lamination Module CLM* upgrade for Evolis Agilia Printers
CLM Card Lamination Module
The card lamination module enables you to protect all your personalized cards for up to 10 years by applying a film. It works in conjunction with Evolis Agilia card printers.
- High-quality lamination: single- or double-sided, integrated card flattener, speed up to 215 cards/hour.
- Wide choice of films: full range of high-capacity varnishes and patches, with or without holograms.
- Intuitive use: LED panel for user guidance, easy access to consumables.
GENERAL FEATURES• Single and double-sided lamination• Standard built-in card flattener• Operates while connected to Agilia
LAMINATION PERFORMANCES• Single-side: up to 215 cards/hour*• Double-side: up to 110 cards/hour*Printing and lamination speeds depend on the printerassociated with the lamination module.
INTERFACES• Infrared (no cable): connection kit with Agilia included
CARD MANAGEMENT AND SPECIFICATIONS• 100-card feeder (0.76 mm - 30 mil) from Primacy/Primacy 2,optional 200-card feeder from Agilia or Primacy 2• Hopper capacity: 100 cards (0.76 mm - 30 mil)• Manual card-to-card issue in stand-alone mode• Card thickness: 0.76 mm (30 mil)• Card types: PVC cards, composite PVC cards, cards PET,polycarbonate cards, special varnishes• Card format : ISO CR80 - ISO 7810 (53.98 mm x 85.60 mm)DISPLAY• LEDs with cleaning alerts, ribbon finished/almost finishedalerts, and more.
EVOLIS HIGH TRUST® RIBBONSTo maximize the quality and service life of printed cards and theoverall performance of the lamination module, use Evolis HighTrust® films.• Automatic recognition and setting• Color matching for easy installation• Films available:- Transparent patch (0.5 or 1 mil): 600 prints / roll- Holographic patch (0.6 or 1 mil): 600 prints / roll- Contact chip cutting patch (0.5 or 1 mil): 600 prints / roll- Alternating 1 mil transparent patches (600prints / roll) with different patch combinations possible: fullcard patch / patch with cut-out for magnetic stripe card /patch with cut-out for contact smart card- Clear varnish: 1,200 prints / roll- Continuous holographic varnish: 1,200 prints / roll- Holographic varnishes: 1,200 prints / roll- Other films on request• List of laminating films available at www.evolis.com
ONSITE UPGRADE OPTION• Installation of a second CLM lamination module to laminatethe two sides of the card with two different films, availableonly with Agilia SOFTWARE∙ Evolis Premium Suite for complete managementof the lamination module (print drivers, administration andsettings, user notifications).Windows and Mac OS* compatible.∙ Evolis SDK (Software Development Kit) for completemanagement and optimal integration into applications and ITsystems
WARRANTY• 3-year warranty• Warranty extension available as an option
WEIGHT & DIMENSIONS13.22 lbs (6 kg), 10.59'' x 8.07'' x 14.56'' (269mm x 205mm x 370mm)
