Fujitsu Primergy RX4770 M4 CTO 4x CPU 48x DIMM Slots 16x 2.5" Bay 2U Server For Sale
When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.
Fujitsu Primergy RX4770 M4 CTO 4x CPU 48x DIMM Slots 16x 2.5" Bay 2U Server
Price: GB $1210.00
Fujitsu Primergy RX4770 M4 CTO 4x CPU 48x DIMM Slots 16x 2.5" Bay 2U Server System Number:S26361-K1587-V200 In Good Condition, Full Working OrderTestedCTO Configure-To-Order - No Processors, No Memory, No Hard Drives Included 2 Year Warranty
Included:
1 xFujitsu Primergy RX4770 M4 16-Bay Rack Server
2 or 4 x Intel Xeon Processor Scalable Family 4x Heatsinks Included
48 x DIMM Slots (12 DDR4 DIMMs per CPU, 6 channels with 2 slots per channel, 16 GB - 6 TB)
4 x 2.5" SAS/SATA + 12 x 2.5" SAS/PCIe Drive Bays
1 x Fujitsu IntelX557-T2Dual-Port 10GBase-TEthernet Network Connection OCP CardX557T2OCPG1P5
Processor quantity and type: 2 or 4 x Intel Xeon Processor Scalable Family
Processor notes: A mimimum of 2 processors must be configured, no mix of different processor types
Memory slots: 48 (12 DIMMs per CPU, 6 channels with 2 slots per channel)
Memory slot type: DIMM (DDR4)
Memory capacity (min. - max.): 16 GB - 6 TB
Memory protection:
Advanced ECC
Memory Scrubbing
SDDC
Memory Mirroring support
Rank sparing memory support
Memory notes: Memory Mirroring with identical modules in both channel pairs of a bank (6 modules per bank), Rank sparing orPerformance Mode with identical modules in all six channels (6 modules per bank).
Interfaces
USB 3.x ports: 5 x USB 3.0 (2x front, 2x rear, 1x internal)
Graphics (15-pin): 2 x VGA (1 x front, 1 x rear)
Serial 1 (9-pin): 1 x RS-232-C
Management LAN (RJ45):
1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s)
Management LAN traffic can be switched to shared onboard LAN controller port, speed and connector is related toinstalled interface card.
Onboard or integrated Controller
RAID controller: All hardware storage controller options are described under Components
SATA Controller: Intel C624, 1 x SATA channel for ODD
LAN Controller:
DynamicLoM based on Intel C624 (Intel X722)
Optional DynamicLoM OCP adaptors:
2 x 10 Gbit/s Ethernet (RJ45)
2 x 10 Gbit/s SFP+
4 x 1 Gbit/s Ethernet (RJ45)
4 x 10 Gbit/s SFP+
All supported features are described in relevant system configurator.
