Gigabit 24VPoE Injector Adapter
Passive PoE(Power Over Ethernet)Injector
as Ubiquiti 24V Gigabit PoE Adapter:
POE-24-7W-G-WH
POE-24-12W-G POE-24-12W-G-WH
POE-24-24W-G POE-24-24W-G-WH
This is a special POE adapter with 24V DC out, it can not Compatible with 802.3af(48v),
please confirm your device is using DC 24v before you puchase this adapter.
If you can not figure out the voltage of your device, we suggest you to buy 48v POE adapter which can follow 802.3af agreement.
Passive PoE devices that support MikroTik PoE with an input voltage of DC 8-30V or 18-30V
This injector can power 24V PoE compatible devices without extra adapters. Just plug the network cable(not included) into your network switch and the "LAN" port, then plug the network cable to your device into the "PoE" port with your existing network cable.This Adapter support 10/100/1000Mbps gigabit ethernet connection, RJ45 PoE port using 4,5,7,8 pin as power transfer, Please do not connect any nonePoE device that does not support the "PoE" port, this will damage your device.
Specification:
CAT5 Ethernet Pin Usage: Data: 1,2,3,4,5,6,7,8 Power: +(4,5),-(7,8)
LED: Power
Voltage Input: AC 100-240 V 50/60Hz
Voltage Output: DC24V 1A
Netork Type: 10/100/1000 Ethernet
Dimension : 84 x 47 x 56mm
Weight -- 106g
Compatible24VUbiquitiPoE:
UBNTAP/UAP
Item Included:
Gigabit 24V 1A PoE Injector Power Over Ethernet Adapter x1
