1 Pair Gigabit Fiber Optical Media Converter 10/100/1000M Single Mode 1 Fiber to 4 RJ45 UPC/APC SC-Port With Outdoor Fiber Wire
Fiber Converter
Type: Fiber Optic Media Converter
Transmission Distance: Single-mode up to 20km
Fiber Optic Connector: 1 UPC/APC SC Port
Ethernet Connector: 4 RJ45 Port
Ethernet Rate: 10/100/1000Mbps
Fiber Port Speed: 1.25G
Wavelength: 1310nm / 1550nm
Fiber Optic Wire
Type: Fiber Optic Extension Wire
Working Wavelength: 1310-1550nm
Tensile Strength: 45kg
Compressive Strength: 600N
Interface type: UPC SC
Min Bending Radius: 3.8cm
Light attenuation: ≤0.3dB
Interchangeability: ≤0.2dB
Insertion and Removal Times: >1000
Working Temperature: -40~85℃
Cable Length: 20M/65.6FT, 30M/98.4FT, 40M/131.23FT, 50M/164FT
Converter Instruction
The Gigabit Ethernet Media Converters with an external power supply are designed to transmit and receive 10/100/1000Mbps data over optical fiber.
The electrical interface will Auto-Negotiate to a 100Mbps or 1000Mbps Ethernet rate without any adjustments.
The optical interface operates at a 1000Mbps Ethernet rate.
Both are environmentally hardened to operate in extreme temperatures.
LED indicators are provided for confirming equipment operating status.
Feature
1 1.25Gbps full-duplex fiber port and 4 1000M Ethernet port.
Each port has the complete LED Indicator light for installation, commissioning, and maintenance.
Support 9K Jumbo Packet.
Support direct forwarding mode, which supports less time delay.
Low power consumption, only 1.5W in full load condition.
Support isolation protection function, good data security.
Small size, suitable for installation in various places.
Auto-negotiation low power consumption chips to ensure very longtime and stable operation.
100% Brand New and High Quality.
Shape & Color: Same as the picture show
The Type As Your Choice!!
The Quantity As Your Choice!!
Thanks for your visit & Happy cooperation!!
Note: Due to nature and measurement tools, coupled with the purely manual measurement and cutting of the cable, it may cause a length error of 1%-5%.
