Diagonal Size 23.8 inch Type a-Si TFT-LCD , LCM

Pixel Format 1920(RGB)×1080  [FHD]  92PPI Configuration RGB Vertical Stripe

Active Area 527.04(H)×296.46(V) mm Outline Dim. -

Bezel Area - Treatment Glare (Haze 0%)

Luminance 250 cd/m² (Typ.) Contrast Ratio 1000:1 (Typ.) (TM)

View Direction Symmetry Response Time 14 (Typ.)(G to G)

Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down Operating Mode ADS, Normally Black, Transmissive [Panelook copyright, copy is strictly prohibited]

IPS Family: AAS, ADS, AHVA, FFS, IPS, New Mode2, PLS, SFT, Vistarich

VA Family: ASV, HVA, MVA, PVA, SVA, UV²A, VA

Support Color 16.7M   72% NTSC Light Source WLED  [3 strings] , 30K hours , W/O Driver

Frame Rate 60Hz  [Panelook copyright, copy is strictly prohibited]

120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC Circuit Touch Panel Without

Interface Type LVDS (2 ch, 8-bit) , 30 pins Connector

Power Supply 5.0V (Typ.)
