HP P1224 SAS RAID controller, PCA 4e/4i, with 1GB FBWC cache module - full-height PCIe SAS RAID controller used in HP StoreOnce backup appliances and related ProLiant-based systems. Removed from service, fully tested and working.
Identification read from the card's own labels:
- HP part number: B6Q91-60104
- Spare part number: 842475-001
- Agency / board model: 25580 (LSI board marking H3-25580-03E)
- Cache module fitted: HP 1GB FBWC, spare 633542-001, assembly 610674-001, serial KU76BP0011
- SAS address on label: 5001438 0266CFBD8
- Interface: PCI Express x8
- Ports: 4 external plus 4 internal SAS (4e/4i)
What is included: the controller with its 1GB FBWC cache module fitted and the full-height bracket, exactly as shown in the photos.
What is not included: capacitor pack / supercap, battery, SAS cables, low-profile bracket, drivers, documentation, or any appliance or server.
Condition and defects: cosmetically clean with light handling marks. The SAS connectors and the gold-finger edge connector are undamaged and the bracket is straight. Please review all photos - they are of the actual card you will receive.
Testing status: tested and working. The controller was installed in a host, detected and initialised normally with the 1GB cache module recognised. It is sold in working order.
Shipping: ships from Fort Worth, Texas, in an anti-static bag with protective padding.
