HPE 200Gb HDR QSFP56 2P OCP3 x16 Ethernet/InfiniBand Network Adapter NIC PCIe4This listing is for 1 (one) HPE Mellanox/nVidia Dual Port 200GbE(Ethernet)and HDR (InfiniBand) QSFP56 OCP3 network adapterPlease note: This adapter requires OCP3 slotWill work in any server, does not have to be HPEWe can integrate this in a full solution, please contact usPlease note: this adapter requires additional OCP x16 bandwidth upgrade cable for HPE Proliant DL Gen10 Plus and Gen10 Plus V2 Servers to have 200Gb/s rates on both ports.We have these cables, please see contact us with any questionsThank youASLOC: OFC-ST-R1-S6Manufacturer specifications:MCX653436A-HDAI SpecificationsPlease make sure to install the ConnectX-6 OCP 3.0 card in a PCIe slot that is capable of supplying 80W.PhysicalSize: 2.99 in. x 4.52 in (76.00mm x 115.00mm)Connector: Dual QSFP56 InfiniBand and Ethernet (copper and optical)Retention Mechanism:Internal LockProtocol SupportEthernet: 200GBASE-CR4, 200GBASE-KR4, 200GBASE-SR4, 100GBASE-CR4, 100GBASE-KR4, 100GBASE-SR4, 50GBASE-R2, 50GBASE-R4, 40GBASE-CR4, 40GBASE-KR4, 40GBASE-SR4, 40GBASE-LR4, 40GBASE-ER4, 40GBASE-R2, 25GBASE-R, 20GBASE-KR2, 10GBASE-LR,10GBASE-ER, 10GBASE-CX4, 10GBASE-CR, 10GBASE-KR, SGMII, 1000BASE-CX, 1000BASE-KX, 10GBASE-SRInfiniBand: IBTA v1.3Auto-Negotiation(a): 1X/2X/4X SDR (2.5Gb/s per lane), DDR (5Gb/s per lane), QDR (10Gb/s per lane), FDR10 (10.3125Gb/s per lane), FDR (14.0625Gb/s per lane), EDR (25Gb/s per lane) port, HDR100 (2 lane x 50Gb/s per lane), HDR (50Gb/s per lane) portData Rate:Ethernet1/10/25/40/100/200 Express Gen 4.0: SERDES @ 16.0GT/s, 16 lanes (3.0 and 1.1 compatible)Power and AirflowVoltage: 3.3VAUX, 12VPowerCable TypeActive ModeSTBY ModeTypical Power(b)Passive Cables21.4W6.6WMaximum PowerPassive Cables26.7W10.45WMaximum power available through QSFP56 port:4.55WAirflow(d)Cable TypeHot Aisle- HSK to PortCold Aisle@35C- Port to HSKActive Mode@55CSTBY Mode@45CActive ModeSTBY to 55°CNon-operational-40°C to 70°CHumidityOperational10% to 85% relative humidityNon-operational10% to 90% relative humidityAltitude (Operational)3050mRegulatorySafetyCB / cTUVus / CEEMCCE / FCC / VCCI / ICES / RCMRoHSRoHS complianta.ConnectX-6 adapters supplement the IBTA auto-negotiation specification to get better bit error rates and longer cable reaches. This supplemental feature only initiates when connected to anotherNVIDIAInfiniBand product.b. Typical power for ATIS traffic load.c. For both operational and non-operational states.d. Airflow numbers are measured while usingNVIDIAHDR optic cable. The maximum allowed temperature (internal sensor) forNVIDIAHDR optic cable is 75C.This listing is for one HPE Mellanox/nVidia Dual Port 200GbE(Ethernet)and HDR (InfiniBand) QSFP56 OCP3 network adapter
Please note: This adapter requires OCP3 slot
Will work in any server, does not have to be HPE
We can integrate this in a full solution, please contact us
Please note: this adapter requires additional OCP x16 bandwidth upgrade cable for HPE Proliant DL Gen10 Plus and Gen10 Plus V2 Servers to have 200Gb/s rates on both ports.
We have these cables, please see contact us with any questions
Thank you
LOC: OFC-ST-R1-S6
Manufacturer specifications:MCX653436A-HDAI Specifications
Please make sure to install the ConnectX-6 OCP 3.0 card in a PCIe slot that is capable of supplying 80W.
Physical
Size: 2.99 in. x 4.52 in (76.00mm x 115.00mm)
Connector: Dual QSFP56 InfiniBand and Ethernet (copper and optical)Retention Mechanism:Internal LockProtocol Support
Ethernet: 200GBASE-CR4, 200GBASE-KR4, 200GBASE-SR4, 100GBASE-CR4, 100GBASE-KR4, 100GBASE-SR4, 50GBASE-R2, 50GBASE-R4, 40GBASE-CR4, 40GBASE-KR4, 40GBASE-SR4, 40GBASE-LR4, 40GBASE-ER4, 40GBASE-R2, 25GBASE-R, 20GBASE-KR2, 10GBASE-LR,10GBASE-ER, 10GBASE-CX4, 10GBASE-CR, 10GBASE-KR, SGMII, 1000BASE-CX, 1000BASE-KX, 10GBASE-SR
InfiniBand: IBTA v1.3
Auto-Negotiation(a): 1X/2X/4X SDR (2.5Gb/s per lane), DDR (5Gb/s per lane), QDR (10Gb/s per lane), FDR10 (10.3125Gb/s per lane), FDR (14.0625Gb/s per lane), EDR (25Gb/s per lane) port, HDR100 (2 lane x 50Gb/s per lane), HDR (50Gb/s per lane) port
Data Rate:Ethernet1/10/25/40/100/200 Express Gen 4.0: SERDES @ 16.0GT/s, 16 lanes (3.0 and 1.1 compatible)Power and Airflow
Voltage: 3.3VAUX, 12VPowerCable TypeActive ModeSTBY Mode
Typical Power(b)
Passive Cables21.4W6.6WMaximum PowerPassive Cables26.7W10.45WMaximum power available through QSFP56 port:4.55W
Airflow(d)
Cable TypeHot Aisle- HSK to PortCold Aisle@35C- Port to HSKActive Mode@55CSTBY Mode@45C
Active Mode
STBY ModeEnvironmental
Temperature
Operational
0°C to 55°C
Non-operational
-40°C to 70°C
Humidity
Operational
10% to 85% relative humidity
Non-operational10% to 90% relative humidityAltitude (Operational)3050mRegulatorySafety
CB / cTUVus / CE
EMCCE / FCC / VCCI / ICES / RCMRoHSRoHS compliant
a.ConnectX-6 adapters supplement the IBTA auto-negotiation specification to get better bit error rates and longer cable reaches. This supplemental feature only initiates when connected to anotherNVIDIAInfiniBand product.
b. Typical power for ATIS traffic load.
c. For both operational and non-operational states.
d. Airflow numbers are measured while usingNVIDIAHDR optic cable. The maximum allowed temperature (internal sensor) forNVIDIAHDR optic cable is 75C.
