The Aruba 340 series access points provide the fastest 802.11ac gigabit data speeds and superb user experience for mobile devices and applications in a digital workplace. Designed with an integrated, 802.3bz Compliant, HPE SmartRate multi-gig Ethernet port to eliminate wired bottlenecks, these APs offer unmatched wireless performance and capacity. The unique and flexible dual-5 GHz architecture of the 340 series offers a way to double 5 GHz capacity where needed, without compromise or restrictions.Thanks to Aruba #39; #39;s advanced ClientMatch technology, the 340 series can automatically detect and classify 802.11ac Wave 2 capable mobile devices. This allows ClientMatch to automatically group Wave 2 capable devices onto a single Wave 2 radio so that performance benefits of multi-user MIMO can be realized - without the adverse effects of slower 802.11ac and traditional 802.11n capable mobile devices. This means increased network capacity and a boost in network efficiency.With maximum data rates of 2,166 Mbps in the 5 GHz band1 and 800 Mbps in the 2.4 GHz band (for an aggregate peak data rate of 3.0 Gbps in dual-band mode and 4.3 Gbps in dual-5 GHz mode), the 340 series APs deliver a best-in-class, next-generation 802.11ac Wi-Fi infrastructure that is ideal for lecture halls, auditoriums, public venues, and high-density office environments.These high performance and high density 340 Series 802.11ac access points support up to 160 MHz channel bandwidth (VHT160), and 4 spatial streams (4SS) for both SU- and MU-MIMO communications.The 340 series APs have an integrated Bluetooth LowEnergy (BLE) radio, which can be used as an Aruba beacon for advanced location, indoor wayfinding, and to enable proximity-based push notification services. The integrated beacon radio also enables the remote management of battery-powered and other standalone beacons in a largescale network of Aruba beacons. It enables businesses to leverage mobility context to develop applications that can
OverviewBrandArubaProduct LineHPE ArubaModelAP-345 (RW) FIPS/TAAManufacturerArubaStorageOptical Drive TypeNoneNetwork & CommunicationCompliant StandardsIEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3bz, Wi-Fi CERTIFIEDConnectivity TechnologyWirelessData Link ProtocolsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11nData Transfer Rate2166 MBpsFeatures4x4 MU-MIMO technology, Adaptive Radio Management (ARM), Advanced Cellular Coexistence (ACC), Air Monitor (AM), AppRF technology, Aruba AirMatch, Aruba Beacons Bluetooth Low-Energy (BLE) technology, ClientMatch, Cyclic Delay Diversity (CDD), Cyclic shift diversity (CSD), DFS support, Firewall protection, Intelligent Power Monitoring (IPM), Link Aggregation Control Protocol (LACP), Low Density Parity Check (LDPC), Maximum Ratio Combining (MRC), MDI/MDI-X switch, Packet aggregation A-MPDU, Packet aggregation A-MSDU, Quality of Service (QoS), Reputation Enabled Defense, Reset button, Secure Core Technology (SCT), SecureJack, Security lock slot (cable lock sold separately), Space Time Blocking Code (STBC), Space-Time Block Code, Spectrum analyzer, Transmit Beam-forming (TxBF) ready, Trusted Platform Module (TPM), Wireless intrusion protectionForm FactorIn-ceilingNetwork Band2.4 GHz, 5 GHzPower Over Ethernet (PoE)PoEProduct TypeWireless access pointSpread Spectrum MethodDSSS, OFDMStatus IndicatorsStatus, SystemWireless Provided1 x 1/2.5GBase-T (PoE) - RJ-45, 1 x 1000Base-T (PoE) - RJ-45, 1 x micro-USB, 1 x USB 2.0 - Type APowerPower Consumption Operational20 wattTechnical InformationAntenna Form Coding Format1024 QAM, 16 QAM, 256 QAM, 64 QAM, BPSK, CCK, OFDM, QPSKMax Operating Temperature122 degree FahrenheitMin Operating Temperature32 degree FahrenheitMTBF640,000 HoursOperating Humidity5 - 93% (non-condensing)Operating System RequiredArubaOS, InstantOSProduct InformationCapacityBSSIDs per radio: 16, Wireless clients per Wi-Fi radio: 256IoT Communications TechnologyBluetooth Low Energy (LE)Packaged Quantity1Ruggedized DesignIndoorService ActivationNoNetwork DeviceMaximum data rate (2.4 GHz): 800 Mbps, Maximum data rate (5 GHz): 2.16 GbpsIncluded ItemsIncluded Accessories2 mounting clipsDimensions & WeightHeight2 inchWeight2.31 lbsWidth8.9 inchDepth8.8 inchCertifications & ListingsCompliant StandardsCB, cTUVus, Directive 2014/30/EU, Directive 2014/53/EU, EN 60601-1-1, EN60601-1-2, FCC, IEC/EN/UL 60950, ISED, LVD 2014/35/EU, UL 2043ENERGY STAR CertifiedNoEPEAT CompliantNoTAA CompliantYesTCO CertifiedNo
