HyperLink Technologies HA2401RTGX-1000 Outdoor 2.4 GHz WiFi Amplifier

The HyperLink Technologies HA2401RTGX-1000 is a professional-grade 1 Watt bi-directional outdoor WiFi amplifier designed to extend the range and improve the performance of 2.4 GHz IEEE 802.11b/g/n wireless LAN systems. It combines a low-noise receive amplifier with a high-power transmit amplifier and incorporates Automatic Gain Control (AGC) to maintain a constant output level regardless of cable losses.

The amplifier automatically senses RF activity and switches between transmit and receive modes, making it ideal for long-distance wireless bridges, industrial WiFi, point-to-point links, WISP installations, surveillance networks, and outdoor wireless infrastructure.

Confirmed Specifications

• Manufacturer: HyperLink Technologies
• Model: HA2401RTGX-1000
• Product Type: Outdoor Bi-Directional WiFi Amplifier
• Frequency Range:
  • 2400–2500 MHz
• Wireless Standards:
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n
• Maximum Transmit Power:
  • 1 Watt (30 dBm)
• Receive Gain:
  • 20 dB nominal
• RF Connectors:
  • RP-TNC Female
• Impedance:
  • 50 Ohms
• Maximum RF Input:
  • 20 dBm (100 mW)
• Operating Mode:
  • Bi-directional
  • Half-duplex
  • Automatic transmit/receive switching
• Automatic Gain Control (AGC):
  • Yes
• Supply Voltage:
  • 12 VDC
• Current Draw:
  • 1.25 A transmit
  • 0.14 A receive
• Environmental Rating:
  • IPX7 Water Resistant
• Operating Temperature:
  • -40°C to +50°C (-40°F to +122°F)
• Dimensions:
  • 5.9 × 2.5 × 1.3 in.
  • 150 × 64 × 33 mm
• Weight:
  • 0.95 lb (0.44 kg)
• Designed for outdoor WiFi bridge and wireless LAN applications.

Typical Applications

• Outdoor WiFi bridges
• Point-to-point wireless links
• Point-to-multipoint networks
• Wireless ISP (WISP)
• Industrial WiFi
• IP surveillance systems
• Campus wireless networks
• Remote telemetry
• Agricultural wireless systems
• Long-range WLAN installations
