IBM 5641249 EC865172 3178C 5291-2 Terminal Base Power Supply Sanken 125V 1.6A
IBM 5641249 EC865172 3178C 5291-2 Terminal Base Power Supply Sanken 125V 1.6A
Open-frame power supply unit manufactured by Sanken Electric for IBM terminal systems. Supplies regulated DC power to IBM 3178C and 5291-2 display terminals via multi-pin card-edge connector.
Specifications & What's Included
- Manufacturer: IBM / Sanken Electric Co., Ltd.
- Model: 5291-2; Secondary Model: 3178C
- MPN: 5641249; Secondary MPN: EC865172
- Input: 125V AC, 1.6A fuse rating; IEC C14 inlet
- Switch Rating: 10A AC125V / 8A AC250V
- Output: Multi-pin card-edge / blue DDK connector
- Form Factor: Open frame
- Manufactured: 1983, Japan
Applications
Terminal base power supplies supported IBM's early display terminal products used in business computing environments from the 1980s onward. The 3178C and 5291-2 were monochrome display terminals deployed in mainframe-connected workstations. This supply converts AC mains to regulated DC outputs required by the terminal's display and control circuits.
Condition: For Parts or Not Working
This IBM 5641249 EC865172 Terminal Base Power Supply has been visually inspected and powers on — the green status LED illuminates when connected. However, we are unable to fully verify all DC output rails or perform a complete functional test of this power supply, and it is therefore being offered in a used, untested condition. The unit appears cosmetically sound with the typical brass-toned iridescent patina common to open-frame PSUs of this era; the heatsink, ventilation cover, and connectors all appear intact with no obvious physical damage. Please review our photo set carefully and contact us with any questions before purchasing. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function. Visit Our Store
