Main Parameters:
Module Size
Module：30*15*5.2mm
FPC：171.5*30*24.03mm
Sensor
1/1.8-Inch IMX678-AAQR1-C
Resolution
3840H x 2160V
Pixel Size
2.0*2.0µm
Output Format
MJPEG, YUV2,
FOV
DFOV:92° HFOV:85° VFOV：54°
Lens
M12 P0.5 3G+3P IR 650NM
TV distortion
<0.5%
FEL
4.2
F/NO
2.0
CAR
12.3°
Focus Type
FF
Shutter Type
Electronic rolling shutter
Output and Power Supply
High Speed USB2.0
Interface
5P 1.0MM
Controllable Parameters
Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White Balance, Backlight Contrast, Exposure
Supported OS
Windows10,Windows11, Android, Linux,
Cable Length
1m
Supported Resolution and Frame Rate
Format
Resolution
Frame Rate (USB2.0)
MJPG
3840x2160(4K)
30FPS
2560x1440(2K)
30FPS
2592x1944(5MP)
30FPS
2048x1536(3MP)
30FPS
1600x1200(2MP)
30FPS
1920x1080 (1080P)
30FPS
1280x720 (720P)
30FPS
640x480 (VGA)
30FPS
YUY2
3840x2160(4K)
1FPS
2560x1440(2K)
1FPS
2592x1944(5MP)
1FPS
2048x1536(3MP)
2FPS
1600x1200(2MP)
3FPS
1920x1080 (1080P)
5FPS
1280x720 (720P)
10FPS
640x480 (VGA)
30FPS
Working Condition:
Operating Voltage
USB DC +5V Supply
Operating Current
180mA
Operating Temperature
-15℃~ 60℃
Storage Temperature
-20℃~ 85℃
Humidity
80 ~85%
