Flexible drive bays configuration for ODD, 2.5" and 3.5" HDD
Supports easy-swap rear fan x 2 for upgrade
Compatible with standard PS2, mini-redundant power supply and CRPS
Expandable storage option with InWin storage kit
GPU holder and adjustable card retainer supporting 350mm dual-slot PCIe cards x 4
Optional rear fan module for GPU
Convertible to tower with chassis stands (optional)
Lockable front door for data security
Tool-free cover for easy installation and quick maintenance
SpecificationIndustry StandardCompatible with EIA-RS310D standard 19" cabinetsM/B Form FactorATX (12" x 9.6"), CEB (12" x 10.5"), EEB (12" x 13")
*The bottom 5.25 drive bay space should be reserved for the EEB motherboard installation.Drive Bay• External: 5.25" x 6, 3.5" x 2
• Internal: 3.5" x 2, 2.5" x 1
Power SupplySupports:
• PS2 single PSU
• 550W/800W/1200W/1600W 1+1 CRPS 80 Plus PlatinumIndicatorsPower status, HDD, LAN activity LEDs
Front Control PanelPower switch, system reset, USB 2.0 x 2
Chassis SecurityIntrusion switch (optional)Cooling FansSupports:
• 80 x 25mm PWM rear fan x 2, 4500RPM
• 80 x 25mm PWM rear fan x 2 (optional), 4200RPM
• 80 x 25mm PWM rear fan x 2 (optional), 4500RPMExpansion SlotFull-height PCIe slots x 8
Material• Material: SGCC
• Thickness: 1.2mm
Rail Kit28" tool-less & ball-bearing slide railsProduct Dimensions (DxWxH; Chassis Only)596x 430 x 174.8mm
(23.5" x 16.9" x 6.9")
Package Dimensions (DxWxH)757 x 595 x 300mm
Weight (Chassis Only)• Net weight: 14.36kg
• Gross weight: 18.07kg
Cubic Feet4.77Container InformationSingle packing with pallets:
• 20': 132pcs
• 40': 288pcs
• 40' HQ: 336pcs
