Intel HNS2600TPFR Compute Module HNS2600TP Family
NEW BROWN BOX
***Shipping DOES NOT include - any taxes/VAT that you may have to pay directly to your government based on your countries import laws. That is a charge you would pay - please check with your government BEFORE committing to buy this item***
ARK | Compare Intel Products
03/04/2022 03:22:42 PM
Intel Compute Module HNS2600TPFR ()
Essentials
Product Collection
Intel Compute Module HNS2600TP Family
Code Name
Products formerly Taylor Pass
Status
Discontinued
Launch Date
Q1'16
Expected Discontinuance
Q3'20
EOL Announce
Friday |July 19 |2019
Last Order
Sunday |July 5 |2020
Last Receipt Attributes
Monday |October 5 |2020
Limited 3-year Warranty
Yes
Extended Warranty Available for Purchase (Select Countries)
Yes
Additional Extended Warranty Details
Intel Compute Module HNS2000 Extended Warranty
# of QPI Links
2
Compatible Product Series
Intel Xeon Processor E5-2600 v4 Family
Board Form Factor
Custom 6.8" x 18.9"
Chassis Form Factor
Rack
Socket
Socket R3
Integrated Systems Available
No
Integrated BMC with IPMI
IPMI 2.0
Rack-Friendly Board
Yes
TDP
145 W
Included Items
Integrated compute module includes: (1) Intel Server Board S2600TPFR w/two 1Gb ports (Intel Ethernet Controller X-540) and Single InfiniBand* FDR IB port (Connect-IB* x8 |QSFP+); (1) 6Gb/s bridge board (FHWKPTPBGB); (1) node power board (FH2000NPB2); (1) one slot PCIe x16 riser card (FHW1U16RISER2); (1) front 1U passive heat sinks (FXXEA84X106HS); (1) rear 1U passive heat sink (FXXCA91X91HS); (3) 4056 dual rotor fan (FXX4056DRFAN2); (1) airduct; (1) 1U node tray
Board Chipset
Intel C612 Chipset
Target Market
High Performance Computing
Supplemental Information
Embedded Options Available
No
Description
A hot-pluggable high density compute module integrated with Intel Server Board S2600TPFR for higher memory capability and flexible configuration options for the Intel Server Chassis H2000G family.
Memory Specifications
Max Memory Size (dependent on memory type)
1 TB
Memory Types
DDR4-1600/1866/2133/2400
Max # of Memory Channels
8
Max Memory Bandwidth
153.6 GB/s
Physical Address Extensions
46-bit
Max # of DIMMs
16
ECC Memory Supported
Yes
Processor Graphics
Integrated Graphics
Yes
Graphics Output
VGA
Discrete Graphics
supported
Expansion Options
Max # of PCI Express Lanes
80
PCI Express Revision
3.0
PCIe x16 Gen 3
1
Connector for Intel I/O Expansion Module x8 Gen 3
1
Riser Slot 1: Total # of Lanes
16
Riser Slot 2: Total # of Lanes
16
Riser Slot 3: Total # of Lanes
24
Riser Slot 4: Total # of Lanes
16
I/O Specifications
# of USB Ports
4
USB Revision
2.0
Total # of SATA Ports
10
RAID Configuration
up to SW Raid 5 (LSI or RSTE)
# of Serial Ports
1
# of LAN Ports
2
Integrated LAN
2x 1GbE
Integrated InfiniBand*
Yes
Package Specifications
Max CPU Configuration
2
Advanced Technologies
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel Remote Management Module Support
Yes
Intel Node Manager
Yes
Intel Fast Memory Access
Yes
Intel Flex Memory Access
Yes
Intel I/O Acceleration Technology
Yes
Intel Advanced Management Technology
Yes
Intel Server Customization Technology
Yes
Intel Build Assurance Technology
Yes
Intel Efficient Power Technology
Yes
Intel Quiet Thermal Technology
Yes
Security & Reliability
Intel AES New Instructions
Yes
Intel Trusted Execution Technology
No
