The KanexPro VGA 1x2 Extender (model VGAEXTX2) is a professional AV extender kit designed to distribute one VGA video input (with embedded stereo audio) to two independent VGA displays over long distances. It uses standard CAT5e/6 Ethernet cables for transmission, supporting resolutions from VGA (640x480) up to WUXGA (1920x1200) at 60Hz. Key features include:
Transmission Distance: Up to 1,000 feet (300 meters) per output via CAT5e/6 cable.
Components: Includes a transmitter unit (with local VGA loop-through output for monitoring), two separate receiver units, and power supplies for rack- or under-desk mounting.
Audio Support: 3.5mm stereo audio input/output on transmitter and receivers for embedding/de-embedding audio signals.
Adjustments: Each receiver has independent gain and peaking rotary switches for fine-tuning brightness, sharpness, and skew to compensate for cable length and minimize signal degradation.
Connectors: 15-pin HD VGA (male/female) for video; RJ45 for CAT5e/6; 3.5mm for audio.
Applications: Ideal for commercial setups like conference rooms, classrooms, digital signage, or broadcast environments requiring reliable VGA distribution without signal loss or interference.
Note: This product has been discontinued by the manufacturer, so availability is limited to new old stock (NOS) or used units.
It ensures buffered, noise-rejecting transmission for high-quality, lossless video and audio delivery to multiple displays.
