802.11 b/g/n wireless LAN
1GHz, single-core CPU
512MB RAM
Micro USB power
installed JumboSPOT UHF(430-440)+VHF(144-146)
(VHF is not the main band, performance reduction)RF extend board.
16G TF CARD Installed PI-STAR panel
support DMR,YSF,P25 mode to QSO with RF To internet
OLED Display
Default installed pi-star to TF card, wifi TEST SSID is TZB,pass is 13902982913,you can change your router 's default SSID and pass it will auto connect.
or you can
also you can use your pc to ping pi-star ,if success,you can open http://pi-star or your pi-star's ip default login user ispi-star,
pass israspberry,then login to SET your CALLSIN,ID,FREQ,and Modem,like the picture:
Display Type is :OLED then Apply Changes.
also your DMR radio must input the Talk Group and Freq ,then you can talk now.
More info
if you have problem you can install the pi-star IMAGE file to TF card again :
· Supports PI-STAR's web based digital voice dashboard and configuration tool
· Supports all four digital amateur modes DMR, D-Star, P25 and System Fusion
· Built-in WiFi: 802.11b/g/n
· Built-in OLED system status display indicating Mode, Talk Group and Call Sign
· Built-in LED indicators for status of Power, PTT, COS and Mode
· Console port SSH 22 for root level access to the operating system
· Quad Core A7 1.2GHz Processor, 512mb DDR3 RAM and 8gb TF Card
· pocket size aluminum enclosurePackage Includes:· Fully assembled and tested Jumbo-Spot-RTQ
· SMA UHF and On board Wifi antennas
- High-concerned chemicalNoneElectricNo
- Accessories TypeSpringWith USBYes
- is_customizedYesModel NumberPIMMDVM01
- Compatible Brand/ModelNoneBrand NameLUSYA
