Product Description
Parameter:
- Connector A : MPO/UPC Male orFemale
- Connector B : LC/UPCMaleSimplex
- Polarity:All are compatible
- Number of cable cores: 24
- Length: 1-5M(Branch 0.5m)
- Diameter: 3.0mm(Branch 2.0mm)
- Fiber Type: OM3
- Insertion Loss: ≤0.35dB
- Return loss: ≥30dB
- Wavelength: 850nm/1300nm
- Durability: 50 times of insertion and removal, Variation in insertion loss is less than 0.2dB
- Bending radius: 10D (static), 20D (dynamic)
- Tensile strength:100N
- Ferrule Material：Ceramic (zirconia)
- Sheath: LSZH jacket
- Operating temperature：-40~+85°C
Package List:
- 1Pcs MPO-LC Fiber Optic Patch Cord
More Types MPO jumpers:
12F MPO/Male-MPO/Female For 40G/100G/200G
12F MPO/Male-MPO/Male For 40G/100G/200G
12F MPO-LC(0.9mm) ForDistribution box
24F MPO-MPO
24F MPO-LC
12F MPO/Male-MPO/Female For 40G/100G/200G
12F MPO/Male-MPO/Male For 40G/100G/200G
8|12F MPO-LC For 100G to 25G /40G to 10G
12F MPO-LC(0.9mm) ForDistribution box
12F MPO/APC-MPO/APC For SR4 400G 800G
16F MPO/APC-MPO/APC For SR8 400G
16F MPO16 - 2*MPO8 For SR8 400G to SR4 200G
24F MPO-MPO
24F MPO-LC
12F MPO/Male-MPO/Female For 40G/100G/200G
12F MPO/Male-MPO/Male For 40G/100G/200G
8|12F MPO-LC For 100G to 25G /40G to 10G
12F MPO-LC(0.9mm)ForDistribution box
16F MPO/APC-MPO/APC For SR8 400G
16F MPO16 - 2*MPO8 For SR8 400G to SR4 200G
24F MPO-MPO
24F MPO-LC
MPO Adapter Panel
MPO Tools
