We promised all the Items will be tested earnestly before shipping, ensure it 100% working in orders. Package Included: 1 x motherboard 1 x I/O back panel 2 x SATA II cable
Technical Tips:
A. Please do not use fake memory or if you're not sure whether your memory fake or not, please do not try it on our motherboard.
B. Please check your CPU, and RAM without problem, then install on the motherboard.
C.If the motherboard can't run correctly, please first check your CPUwhether can be compatible with our motherboard, then check your videocard or power supply.
D. 90% can't boot problem was caused by RAM, please don't use single side RAM.
Parts Specification:
-8th Generation Intel® Core™ processors supporting LGA1151, and Intel® Pentium® Gold and Celeron® processors
-2xDDR4 slots, support up to 32GB combined
-Support DDR4 2666/ 2400/ 2133 MHz
-Support dual channel mode
-Supports non-ECC, unbuffered memory
-Supports Intel® Extreme Memory Profile (XMP)
-1xPCIe 3.0 x16 slot
-2xPCIe 3.0 x1 slots
-1xVGA port, supports the highest resolution 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz1
-1xDVI-D port, supports up to 1920x1200@60Hz1
-1xHDMI™ 1.4 port, supports up to 4096x2160@30Hz1
-Up to 2 monitors can be supported at the same time.
Storage
-Intel® H310 Chipset
-4xSATA 6Gb/s ports
-1xM.2 slot (M key)
-Supports up to PCIe 2.0 x4 and SATA 6Gb/s
-Support 2242/2260/2280 specification storage devices
USB
-Intel® H310 Chipset
-4xUSB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on back panel, 2 via onboard USB ports)
-6xUSB 2.0 (High-speed USB) ports (4 on back panel, 2 via onboard USB)
Sound effect-Realtek® ALC887 decoder chip
-7.1-channel high-quality soundBuilt-in interface
-1 x 24-pin ATX main power connector
-1 x 8-pin ATX 12V power connector
-4xSATA 6Gb/s ports
-1xUSB 3.1 Gen1 port (can support 2 additional USB 3.1 Gen1 ports)
-1xUSB 2.0 port (can support 2 additional USB 2.0 ports)
-1 x 4-pin CPU fan connector
-1 x 4-pin system fan connector
-1xpanel audio interface
-1xserial interface
-2xsystem panel connectors
-1xTPM module interface
-1xchassis opening port
-1xLED interface
-1xclear CMOS function jumper
Internal I/O Ports
-1 x High AMP Fan header (4-pin)
-2 x RGB Header(s)
-3 x 3D Mount screw port(s)
-1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
-1 x ROG extension (ROG_EXT) header(s)
-3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s)
-1 x CPU OV
-1 x USB 3.1 Gen 2 front panel connector
-1 x AAFP connector
-1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (PCIE mode only)
-1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode)
-6 x SATA 6Gb/s connector(s)
-1 x CPU Fan connector(s)
-1 x CPU OPT Fan connector(s)
-2 x Chassis Fan connector(s)
-1 x 24-pin EATX Power connector(s)
-1 x 8-pin ATX 12V Power connector(s)
-1 x Front panel connector(s)
-1 x System panel(s) (Chassis intrusion header is inbuilt)
-1 x 5-pin EXT_FAN(Extension Fan) connector
-1 x Thermal sensor connector(s)
-1 x Clear CMOS jumper(s)
-1 x 14-1 pin TPM connector
-1 x COM port header
-1 x T_Sensor Connector
-1 x AIO PUMP Header
Backplane interface
-PS/2 keyboard/mouse port
-VGA port
-HDMI interface
-USB 3.1 Gen1
-LAN interface
-HD audio interface
-USB 2.0 interface
-DVI-D interface
-USB 2.0 interface
Mounting hole
-6 mounting holes
-ATX ; 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
