ChipsetINTEL Z890CPUSupports Intel® Core™ Ultra Processors (Series 2)
LGA 1851Memory4x DDR5 UDIMM, Maximum Memory Capacity 256GB
Memory 支持 DDR5 8800 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s
Max. overclocking frequency:
• 1DPC 1R Max speed up to 8800+ MT/s
• 1DPC 2R Max speed up to 7200+ MT/s
• 2DPC 1R Max speed up to 6400+ MT/s
• 2DPC 2R Max speed up to 5600+ MT/s
Supports Intel® POR Speed and JEDEC Speed
Supports Memory Overclocking and Intel® XMP 3.0
Supports Dual-Controller Dual-Channel mode
Supports Non-ECC, Un-buffered memory
Supports CUDIMM
Onboard Graphics1x HDMI™
Support HDMI™ 2.1, maximum resolution of 4K 60Hz*
1x DisplayPort
Support DisplayPort 1.4, maximum resolution of 4K 60Hz*
1x Type-C DisplayPort
Thunderbolt™ 4 port, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz*
*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.Slot2x PCI-E x16 插槽（数量）
PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 4.0 supports up to x4 (From Chipset)AudioRealtek® ALC897 Codec
7.1-Channel High Definition AudioStorage3x M.2 (Qty)
M.2_1 源 (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260/2242 devices
M.2_2 源 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_3 源 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
4x SATA 6G (Qty)
*Please refer to the manual for M.2 SSD heatsink restrictions.RAIDSupports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage devicesOnboard Thunderbolt1x Thunderbolt4 ports (Rear)
Supports up to 40Gbps transfer rate with Thunderbolt devices
Supports up to 20Gbps transfer rate with USB4 devices
Supports up to 10Gbps transfer rate with USB 3.2 devices
Supports up to 5V/3A,15W power charging
Each port can daisy-chain up to three Thunderbolt 4 devices or five Thunderbolt 3 devices
Supports up to 8K displayUSB2x USB 2.0 (后置)
4x USB 2.0 (前置)
2x USB 5Gbps Type A (Rear)
4x USB 5Gbps Type A (Front)
1x USB 10Gbps Type A (Rear)
1x USB 10Gbps Type C (Rear)
1x USB 10Gbps Type C (Front)LANRealtek® 8126 5G LANInternal IO1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x Power Connector(PCIE_PWR 8pin)
1x CPU Fan
1x PUMP_SYS Fan
3x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Com Port (JCOM)
1x Tuning Controller connector(JDASH)
2x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 接口
4x USB 5Gbps Type A ports
1x USB 10Gbps Type C portsWIRELESS LAN & BLUETOOTHWi-Fi 7 Solution
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.9Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax/ be
Supports Bluetooth® 5.4**, MLO, 4KQAM
LED FEATURE4x EZ Debug LED 1x EZ Memory Detection LEDBACK PANEL PORTS
- Display Port
- USB 2.0
- USB 5Gbps (Type-A)
- 5G LAN
- Wi-Fi / Bluetooth
- HDMI™
- Thunderbolt™ 4 40Gbps (Type-C)
- Clear CMOS Button
- USB 10Gbps (Type-C)
- USB 10Gbps (Type-A)
- Audio Connectors
OPERATING SYSTEMSupport for Windows® 11 64-bit
