Please note: The motherboard has been opened (as it will be tested (including all interfaces and slots) before shipment to ensure that there are no issues with the motherboard before it is dispatched)
(If you are sensitive to any traces of testing, please do not purchase.) Processor

Supports 9th/ 8thGen Intel®Core™ / Pentium®Gold / Celeron®processors for LGA 1151 socket

Chipset

Intel®Z390 Chipset

Memory

• 4 x DDR4 memory slots, support up to 128GB1
  • Supports DDR4 4400(OC)/ 4300(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC) / 2800(OC)/ 2666/ 2400/ 2133 MHz1
• Supports Dual Channel mode
• Supports non-ECC, un-buffered memory
• Supports Intel®Extreme Memory Profile (XMP)

1. Please refer to Compatibility for more information on compatible memory

Slots

• 2 x PCIe 3.0 x16 slots(support x16/x4 mode)
• 4 x PCIe 3.0 x1 slots
• 1 x M.2 slot with E key for Integrated Intel® Wireless-AC(CNVi) module only

Onboard Graphics

• 1 x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz
• 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
• 1 x DisplayPort, supports a maximum resolution of 4096x2304@60Hz

*No Display support when using the Processor model with suffix “F”

Multi-GPU

• Supports 2-Way AMD®CrossFire™Technology

Storage Intel®Z390 Chipset

• 6 x SATA 6Gb/s ports1
• 1 x M.2 slot (Key M)
  • Supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices
  • Intel®Optane™ Memory Ready2

1. The SATA2 will be unavailable when installing M.2 SATA device into M.2 slot.
2. Before using Intel®Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.

RAID Intel®Z390 Chipset

• Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices

USB Intel®Z390 Chipset

• 2 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-A port and 1 Type-C port on the back panel)
• 6 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 3.1 connectors
• 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)1

1. The CNVI_1 and JUSB2 share the same bandwidth. Please refer to page 32 for details.

Audio Realtek®ALC892/897 Codec

• 7.1-Channel High Definition Audio

LAN

• 1 x Intel®I219-V Gigabit LAN controller

Internal connectors

• 1 x 24-pin ATX main power connector
• 1 x 8-pin ATX 12V power connector
• 1 x 6-pin ATX 12V power connector
• 6 x SATA 6Gb/s connectors
• 2 x M.2 slots (1 M-Key slot,1 E-Key slot)
• 2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
• 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
• 1 x 4-pin CPU fan connector
• 1 x 4-pin Water Pump connector
• 5 x 4-pin system fan connectors
• 1 x Front panel audio connector
• 2 x System panel connectors
• 1 x Chassis Intrusion connector
• 1 x 4-pin RGB LED connector
• 1 x Serial Port connector
• 1 x Clear CMOS jumper
• 1 x Parallel port connector
• 1 x TPM module connector
• 1 x thunderbolt Add-on card connector
• 1 x Front OC button connector

Back panel ports

1. PS/2 Combo
2. VGA
3. USB 3.1 Gen2 Type A+C
4. LAN
5. HD Audio Connectors
6. USB 2.0
7. DVI-D
8. Displayport
9. USB 3.1

Dimensions

• 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
• ATX Form Factor

Mounting

9 mounting holes

Operating System

Support for Windows®10 64-bit
