BRAND NEW IN BOX, SHIPS SAME DAY TheUbiquitiUniFi Device Bridge(UDB)is a plug-and-play, wireless bridging PoE adapter with integrated UniFi WiFi Auto-Link. Here are its key specifications and features: Key Features: - PoE: (1) GbE LAN port that provides up to 15W of PoE
- 5 GHz Radio: 5 GHz band with up to 867 Mbps throughput rate
- Compatibility: Compatible with UniFi Protect PoE cameras, Talk phones, and various IoT devices via an Ethernet connection
Technical Specifications: Mechanical: - Dimensions: 130 x 55 x 34 mm (5.1 x 2.2 x 1.3")
- Weight: 200 g (7.1 oz)
- Enclosure Material: Polycarbonate
- Mount Material: Polycarbonate
Hardware: - Management Interface: WiFi
- Networking Interface: (1) GbE RJ45 port
- PoE Interface: (1) Passive PoE output
- Button: (1) Factory-reset
- LEDs:
- (4) Blue: signal
- (1) White/blue: indicator
- Power Method: 100–240V AC, 0.45A Max., 50/60 Hz
- Max. Power Consumption:
- AC input: 25W
- Excluding PoE output: 10W
- Max. PoE Wattage per Port: 15W
- Supported Voltage Range: 100–240V AC
- WiFi Standards: 802.11a/n/ac
- Max. TX Power: 21 dBm (5 GHz)
- MIMO: 2x2 (5 GHz)
- Max. Data Rate: 866.7 Mbps (BW80)
- Antenna Gain:
- Internal antenna: 5 dBi
- External omni antenna: 4 dBi
- Antenna:
- (1) Internal antenna
- (1) RP-SMA connector for external omni-antenna
- Mounting: Wall (Included)
- Ambient Operating Temperature: -10 to 40° C (14 to 104° F)
- Ambient Operating Humidity: 5 to 95% noncondensing
- Certifications: CE, FCC, IC
Supported Data Rates: - 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
- 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
- 802.11ac: 6.5 Mbps to 866.7 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
TheUniFi Device Bridgeis ideal for providing wireless bridging and PoE capabilities to various UniFi devices.  |
|
