Napatech NT200A02-N NT200A02-01 SmartNICNapatech NT200A02-N NT200A02-01 SmartNICProduct Overview:

The Napatech NT200A02-N SmartNIC is a high-performance network interface card designed for real-time, line-rate performance in demanding applications such as network monitoring, cybersecurity, and data analytics. It provides full packet capture of network data at 100 Gbps and can handle traffic bursts up to 200 Gbps with zero packet loss, ensuring reliable and accurate data capture even under high-load conditions.

Equipped with nanosecond precision time-stamping and the ability to merge packets from multiple ports, the NT200A02-N ensures correct timing and sequencing of packets. This makes it ideal for applications requiring precise network traffic analysis and replay, such as testing, simulation, and performance monitoring.

The SmartNIC features a modular design with two QSFP28 network ports, offering flexibility in network connectivity. It also includes support for IEEE 1588 Precision Time Protocol (PTP) and Pulse Per Second (PPS) synchronization, enabling accurate time synchronization across networked systems.

This unit is sold AS IS, untested, and without accessories. Cosmetic condition is good with minor signs of use.

Key Specifications:

• Manufacturer: Napatech

• Model: NT200A02-N

• Part Number: NT200A02-01

• Form Factor: Full-height, half-length PCIe Gen3 x16

• Network Ports: 2 × QSFP28

• Supported Speeds: 100 Gbps full-duplex, 200 Gbps burst

• Time Synchronization: IEEE 1588 PTP, PPS input/output

• Time-Stamps: Nanosecond precision

• FPGA: Xilinx UltraScale+ VU5P

• Memory: 12 GB DDR4 SDRAM

• Power Consumption: 75 Watts (typical)

• Dimensions: 1/2-length and full-height PCIe

• Weight: 355 g

• MTBF: 317,821 hours (according to UTE C 80-810)

• Condition: AS IS, untested, no accessories

• Cosmetic Condition: Good, minor signs of use

Key Features:

• High-speed packet capture at 100 Gbps with zero packet loss

• Nanosecond precision time-stamping for accurate traffic analysis

• Modular design with two QSFP28 ports for flexible connectivity

• Support for IEEE 1588 PTP and PPS synchronization

• Programmable FPGA for customizable offload and processing

• 12 GB DDR4 SDRAM buffer for burst traffic handling

• Low CPU utilization (<5% of one core)

• Compatible with Linux and libpcap for easy integration

The Napatech NT200A02-N SmartNIC is a versatile and high-performance network interface card ideal for applications requiring precise and reliable network traffic capture and analysis. Its modular design, high-speed capabilities, and advanced time synchronization features make it suitable for a wide range of use cases, including cybersecurity, network performance monitoring, and data analytics.

This unit is sold AS IS and untested, offering an opportunity for labs or refurbishers to acquire a quality instrument at a reduced price.
