Product InformationSKU829457Mfr Part#Z890AYWWIFIWUPC197105752115General Z890BIOS256 (128+128) Mb Flash ROM, UEFI AMI BIOSManageabilityWOL
PXECPU SupportIntel CPU SupportCore Ultra ProcessorsSocket TypeLGA 1851Memory SpecificationsECCNon-ECC; Non-RegisteredMemory TypeDDR5-4800
DDR5-5200
DDR5-5400
DDR5-5600
DDR5-5000
DDR5-6400
DDR5-6200
DDR5-6000
DDR5-5800Memory Speeds Supported9066+ MHz (OC)Memory Slots4 x 288pin DIMMMemory Channel SupportDual ChannelMax Memory Supported256GBMaximum Memory Supported Per Slot64GBVideo SpecificationsOnboard Graphic ChipsetRequires CPU with Integrated GraphicsStorage SpecificationsM.2 Port Type2280
22110SATA Express4 x M.2 Socket 3
M KeySATA 6Gb/s4RAID SupportRAID 0
RAID 1
RAID 5
RAID 10Audio SpecificationsAudio Channels7.1NetworkingWiFi SupportOnboard WiFiLAN ChipsetRealtek 2.5Gb EthernetLAN Speed10/100/1000/2500MbpsWireless Technology802.11b
802.11g
802.11a
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
Bluetooth v5.3Expansion SlotsPCI Express 4.0 x163PCI Express 5.0 x161Back Panel PortsLAN Ports1 x 10/100/1000/2500 RJ-45 LANAudio Ports1 x 3.5 mm Microphone
1 x 3.5 mm Line-In
1 x 3.5 mm Line-OutSpecialty Ports2 x WiFi Antenna PortsUSB 2.04 x USB 2.0 (Type-A)USB 3.11 x USB 3.2 (Gen 2x2 Type-C)
3 x USB 3.2 (Gen 2 Type-A)Video Connectors1 x DisplayPort 1.4Internal I/O & ConnectorsHeaders4 x System Fan Header
1 x Water Pump Header
2 x CPU Fan HeaderUSB2 x USB 2.0 Headers (4 Ports)
2 x USB 3.2 Gen 1 Type-A Headers (4 Ports)
1 x USB 3.2 Gen 2x2 Type-C Header (1 Port)Other I/O3 x Addressable LED HeadersPowerPower Connectors1 x 24-pin ATX Connector
2 x 8-pin +12 V ConnectorATX Connector24-pin ATX Power ConnectorPhysical SpecificationsDepth12.00 in. (305.00 mm)Width9.61 in. (244.00 mm)Form FactorATXWarrantyParts3 YearsLabor3 YearsPackage ContentsWhat's in the BoxMotherboard, 2x SATA 6Gb/s cables, 1x ASUS Wi-Fi moving antenna, 2x M.2 rubber packages, 1x Screw package for M.2 SSD, 1x Quick start guide
