User-Configurable Multi-Sensor True Day/Night Indoor/Outdoor Dome IP Camerawith SNAPstream™ (Smart Noise Adaptation and Processing)
Image Sensor
Pixel Pitch
2.2 μm
Minimum Illumination
Color (Day Mode): 0.3 lux
Color Binning (Day Mode): 0.15 lux
B/W (Night Mode): 0.03 lux, IR sensitive
Resolutions
Full Field of View:
Total: 10240 (H) x 1920 (V)
Per Sensor: 2560 (H) x 1920 (V)
1/4 Resolution:
Total: 5120 (H) x 960 (V)
Per Sensor: 1280 (H) x 960 (V)
Dynamic Range
70.1 dB
Frame Rates
At Max Resolution: 7 fps (10240 x 1920)
1/4" Resolution: 10 fps (5120 x 960)
Binning Mode: 24 fps (5120 x 960)
Lens
2.8mm
Aperture
f/1.6
Field of View
114°
Optics
Remote focus, pixel binning mode
Simultaneous delivery of full field of view and zoomed images
Shutter Speed
Programmable; controls motion blur from 1 ms to 500 ms
Motion Detection
Real-time, 1024 detection zones
Privacy Masking
Unlimited
Cropping
Flexible: Resolution windowing down to 1x1 pixel for JPEG and 2x2 pixels for H.264
Backlight Compensation
Auto multi-matrix white balance
Wide Dynamic Range
Auto switch control adjustment between WDR and LDR modes
Efficiency
Bit rate and bandwidth limitation control
Bandwidth and storage savings by running at 1/4 resolution
Sharpness
Selectable enhancement level
Additional Features
MoonLight Mode: Extended exposure and noise cancellation
Flicker Control: 50/60 Hz selectable
Programmable resolution, brightness, saturation, gamma, tint
Simultaneous delivery of full field of view and zoomed images
Electronic pan, tilt, zoom (PTZ)
Auto exposure (AE) and gain control (AGC) > 120 dB
Programmable shutter speed to help control motion blur
Compression
H.264 (MPEG-4, Part 10) / MJPEG
21 levels of quality
Network Protocols
RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, IPv4, IPv6, QoS
Network Interface
100Base-T Ethernet
Multi-Streaming
8 non-identical streams
Industry Standards
PSIA conformant
Listings
UL (CB)
FCC Compliance
47 CFR 15 Class A
Environmental
RoHS, REACH, WEEE
Marking
(CE) EN 55022:2010 Class A, EN 55024:2010, EN 61000-3-2:2006+A1:2009+A2:2009, EN61000-3-3: 2008, (UL) IEC 60950-1 (ed. 2) and IEC 60950-22 (ed. 1)
Operating Temperature
-40 to 122°F / -40 to 50°C
Humidity
0 to 90% (non-condensing)
Storage Temperature
-40 to 140°F / -40 to 60°C
Alarm Input / Output
1 input / 1 output
Power Over Ethernet
PoE 802.3af, Class 3
Auxiliary Power Required
18 to 48 VDC, 24 VAC
Max Power Consumption
Aux: 14 W (max)
