Product InformationMfr Part#B850IAORPROUPC889523046364General B850BIOS256 Mb Flash ROM, UEFI AMI BIOSManageabilityPnP 1.0a
WfM 2.0
SM BIOS 2.7
ACPI 5.0
DMI 2.7CPU SupportAMD CPU SupportRyzenSocket TypeAM5Memory SpecificationsECCNon-ECC; Non-RegisteredMemory TypeDDR5-4800
DDR5-5200
DDR5-4400Memory Speeds Supported8400(OC) / 8200(OC) / 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MHzMemory Slots2 x 288pin DIMMMemory Channel SupportDual ChannelMax Memory Supported128GBMaximum Memory Supported Per Slot64GBVideo SpecificationsOnboard Graphic ChipsetRequires CPU with Integrated GraphicsStorage SpecificationsM.2 Port Type2280SATA Express2 x M.2 Socket 3
M KeySATA 6Gb/s2RAID SupportRAID 0
RAID 1
RAID 5
RAID 10Audio SpecificationsAudio ChipsetRealtek ALC4080Audio Channels2.0NetworkingWiFi SupportOnboard WiFiLAN ChipsetRealtek 2.5Gb EthernetLAN Speed10/100/1000/2500MbpsWireless LAN ChipsetRealtek Wi-Fi 7 RTL8922AEWireless Technology802.11b
802.11g
802.11a
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
Bluetooth v5.4
WiFi 7 (802.11be)
WiFi 6E (802.11ax)Expansion SlotsPCI Express 5.0 x161Back Panel PortsLAN Ports1 x 10/100/1000/2500 RJ-45 LANAudio Ports1 x 3.5 mm Microphone
1 x 3.5 mm Line-OutSpecialty Ports2 x WiFi Antenna PortsUSB 2.02 x USB 2.0 (Type-A)USB 3.11 x USB 3.2 (Gen 2 Type-C)
2 x USB 3.2 (Gen 1 Type-A)
2 x USB 3.2 (Gen 2 Type-A)Video Connectors1 x HDMI 2.1Internal I/O & ConnectorsHeaders1 x CPU Fan Header
1 x Water Pump Header
1 x System Fan HeaderUSB1 x USB 2.0 Header (2 Ports)
1 x USB 3.2 Gen 1 Type-A Header (2 Ports)
1 x USB 3.2 Gen 2 Type-C Header (1 Port)Other I/O2 x Addressable LED HeadersPowerPower Connectors1 x 24-pin ATX Connector
1 x 8-pin +12 V ConnectorATX Connector24-pin ATX Power ConnectorPhysical SpecificationsDepth6.70 in. (170.00 mm)Width6.70 in. (170.00 mm)Form FactorMini-ITXWarrantyParts3 YearsLabor3 YearsPackage ContentsWhat's in the BoxMotherboard, Manual, Antenna, 2x SATA Cables, 2x Fan Extension Cables, Screws, M.2 Mounting Screws, M.2 Thermal Pads
