Capabilities
Physical
Size: 4.89in. x 2.71in (124.22mm x 68.90mm)
Connector: Dual SFP28 Ethernet (copper and optical)
Protocol Support
Data Rate:
Ethernet
1/10/25 Gb/s
Ethernet: 25GBASE-R, 20GBASE-KR2, 10GBASE-LR,10GBASE-ER, 10GBASE-CX4, 10GBASE-CR, 10GBASE-KR, SGMII, 1000BASE-CX, 1000BASE-KX, 10GBASE-SR
PCI Express Gen 3.0/4.0: SERDES @ 16.0GT/s, 8 lanes (2.0 and 1.1 compatible)
Power and Airflow Specifications(a)
Voltage: 3.3Aux
Maximum current: 100mA
Power
Cable
PCIe Gen 3.0
PCIe Gen 4.0
Typical Power
Passive Cables
10.88W
11.29W
Maximum Power
Passive Cables
15.55W
15.96W
Maximum power available through SFP28 port: 1.5W (per port)
Airflow @ 55Cb)
Cable Type
Hot Aisle - Heatsink to Port
Passive Cable
200LFM
Active 0.8W Cable
400 LFM
Active 1.5W Cable
450LFM
Environmental
Temperature
Operational
0°C to 55°C
Non-operational
-40°C to 70°C(c)
Humidity
Operational
10% to 85% relative humidity
Non-operational
10% to 90% relative humidity
Altitude (Operational)
3050m
Regulatory
Safety
CB / cTUVus / CE
EMC
CE / FCC / VCCI / ICES / RCM
RoHS
RoHS compliant
a. Typical power for ATIS traffic load.
b. Airflow is measured in wind tunnel. Contact NVIDIA for airflow numbers with other active modules' power levels.
c. The non-operational storage temperature specifications apply to the product without its package.
