Introduction
Features
Application Field
Application
Simple Transparent transmission
Various parameter setting method
User can set parameter by module itself without going through another computer to configure. This setting method is used in the following situation: user have to configure IP address and destination IP address on site. AT command can meet the demand. After MCU connects serial server module by TTL (UART), MCU can configure setting by AT command.
Work VoltDC 5.0～36.0 VWork Current116mA@5V/53mA@12VEthernet Port10/100Mbps auto switch between cross and direct connectionBaud rate600-230.4K bpsSerial PortRS232*1 / RS485*1 / RS422*1
Network ProtocolIP, TCP/UDP, ARP, ICMP, IPV4IP ModeStatic IP, DHCPDNSUser-defined DNS server addressConfigureSoftware/Webpage/AT commandWork ModeTCP Server/TCP Client/UDP Server/UDP
