Socket compatibility Intel LGA2011-0 & LGA2011-3(Square ILM), LGA1156, LGA1155, LGA1151, LGA1150 & AMD AM2, AM2+, AM3, AM3+, FM1, FM2, FM2+ (backplate required)



Height (without fan) 158 mm



Width (without fan) 125 mm



Depth (without fan) 45 mm



Height (with fan) 158 mm



Width (with fan) 125 mm



Depth (with fan) 71 mm



Weight (without fan) 580 g



Weight (with fan) 755 g



Material Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating



Max. TDP see TDP guide



Fan compatibility 120x120x25



Scope of Delivery NF-F12 PWM premium fan
Low-Noise Adaptor (L.N.A.)
NT-H1 high-grade thermal compound
SecuFirm2™ Mounting Kit
Anti-vibration pads and fan-clips for second NF-F12
Noctua Metal Case-Badge


Warranty 6 Years

Fan specifications



Model Noctua NF-F12 PWM



Bearing SSO2



Max. Rotational Speed (+/- 10%) 1500 RPM



Max. Rotational Speed with L.N.A. (+/- 10%) 1200 RPM



Min. Rotational Speed (PWM, +/-20%) 300 RPM



Max. Airflow 93,4 m³/h



Max. Airflow with L.N.A. 74,3 m³/h



Max. Acoustical Noise 22,4 dB(A)



Max. Acoustical Noise with L.N.A. 18,6 dB(A)



Input Power 0,6 W



Voltage Range 12 V



MTBF > 150.000 h
