Gigabyte GA-G41MT-S2PT V2.1 MotherboardIntroduction

Industry's Leading All Solid Capacitor Motherboard Design
• GIGABYTE 3x USB Power with On/Off Charge USB ports
• Revolution energy saving design with Easy Energy Saver technology
• Supports 45nm Intel Core 2 multi-core processors with FSB 1333 MHz
• Integrated Intel Graphics Media Accelerator X4500 (DirectX 10)
• Features high speed Gigabit Ethernet.
• Hi-def 108dB Signal-to-noise ratio Blu-ray™ DVD audio playback
• DualBIOS™ protection with 3TB+ HDD boot up capability
• Meet European Union ErP(Energy-related Products) requirement

CPU

1. Support for an Intel®Core™ 2 Extreme processor/Intel®Core™ 2 Quad processor/Intel®Core™ 2 Duo processor/ in the LGA775 package
2. L2 cache varies with CPU

(Please refer "CPU Support List" for more information.)

Front Side Bus

1. 1333/1066/800 MHz FSB

Chipset

1. NorthBridge: Intel®G41 Express Chipset
2. SouthBridge: Intel®ICH7

Memory

1. 2 x 1.5V DDR3 DIMM sockets supporting up to 8 GB of system memory
   * Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB.
2. Dual channel memory architecture
3. Support for DDR3 1333 (O.C.)/1066/800 MHz memory modules

(Please refer "Memory Support List" for more information.)

Onboard Graphics

NorthBridge:

1. 1 x D-Sub port

Audio

1. Realtek ALC887 audio codec
2. High Definition Audio
3. 2/4/5.1/7.1-channel
   * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.

LAN

1. 1 x Atheros AR8151 chip (10/100/1000 Mbit)

Expansion Slots

1. 1 x PCI Express x16 slot, running at x16
2. 1 x PCI Express x1 slot
3. 2 x PCI slots

Storage Interface

SouthBridge:

1. 1 x IDE connector supporting ATA-100/66/33 and up to 2 IDE devices
2. 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices

USB

SouthBridge:

1. Up to 8 USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

Internal I/O Connectors

1. 1 x 24-pin ATX main power connector
2. 1 x 4-pin ATX 12V power connector
3. 1 x IDE connector
4. 4 x SATA 3Gb/s connectors
5. 1 x CPU fan header
6. 1 x system fan header
7. 1 x front panel header
8. 1 x front panel audio header
9. 2 x USB 2.0/1.1 headers
10. 1 x Clear CMOS jumper

Back Panel Connectors

1. 1 x PS/2 keyboard port
2. 1 x PS/2 mouse port
3. 1 x parallel port
4. 1 x serial port
5. 1 x D-Sub port
6. 4 x USB 2.0/1.1 ports
7. 1 x RJ-45 port
8. 3 x audio jacks (Line In/Line Out/Microphone)

I/O Controller

1. iTE IT8720/IT8718 chip

H/W Monitoring

1. System voltage detection
2. CPU temperature detection
3. CPU/System fan speed detection
4. CPU overheating warning
5. CPU/System fan fail warning
6. CPU fan speed control
   * Whether the CPU fan speed control function is supported will depend on the CPU cooler you install.

BIOS

1. 2 x 8 Mbit flash
2. Use of licensed AWARD BIOS
3. Support for DualBIOS™
4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

Unique Features

1. Support for @BIOS
2. Support for Q-Flash
3. Support for Xpress BIOS Rescue
4. Support for Download Center
5. Support for Xpress Install
6. Support for Xpress Recovery2
7. Support for EasyTune
   * Available functions in EasyTune may differ by motherboard model.
8. Support for Easy Energy Saver
   * Due to the hardware limitation, you must install the Intel®Core™ 2 Extreme/Core™ 2 Quad/Core™ 2 Duo/Pentium Dual-Core/Celeron Dual-Core/Celeron 400 Series CPU to enable support for Easy Energy Saver.
9. Support for Smart Recovery
10. Support for ON/OFF Charge
11. Support for 3TB+ Unlock
12. Support for Q-Share

Form Factor

1. Micro ATX Form Factor; 24.4cm x 19.4cm

Remark

1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
2. Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website.
